2023.06.06

★ 클러스터에 몇 개의 clusterrole이 정의되어 있나요?

-> 69개


controlplane ~ ➜  kubectl get clusterrole --no-headers | wc -l
69

controlplane ~ ➜

★ 클러스터에 몇 개의 clusterrolebindings이 존재하나요?

-> 54개


controlplane ~ ➜  kubectl get clusterrolebindings --no-headers | wc -l
54

controlplane ~ ➜

★ cluster-admin clusterrole은 어떤 네임스페이스에 속하나요?

-> 클러스터 역할은 클러스터 전체에 속하며 네임스페이스의 일부가 아니다.


controlplane ~ ➜  kubectl describe clusterrole cluster-admin
Name:         cluster-admin
Labels:       kubernetes.io/bootstrapping=rbac-defaults
Annotations:  rbac.authorization.kubernetes.io/autoupdate: true
PolicyRule:
Resources  Non-Resource URLs  Resource Names  Verbs
---------  -----------------  --------------  -----
*.*        []                 []              [*]
[*]                []              [*]

controlplane ~ ➜

★ cluster-admin 역할은 어떤 사용자/그룹에 바인딩되나요?

-> Group system:masters


controlplane ~ ➜  kubectl describe clusterrolebinding cluster-admin
Name:         cluster-admin
Labels:       kubernetes.io/bootstrapping=rbac-defaults
Annotations:  rbac.authorization.kubernetes.io/autoupdate: true
Role:
Kind:  ClusterRole
Name:  cluster-admin
Subjects:
Kind   Name            Namespace
----   ----            ---------
Group  system:masters

controlplane ~ ➜

★ cluster-admin 역할은 어떤 수준의 권한을 부여하나요?

-> 클러스터의 모든 리소스에 대해 모든 작업 수행


controlplane ~ ➜  kubectl describe clusterrole cluster-admin
Name:         cluster-admin
Labels:       kubernetes.io/bootstrapping=rbac-defaults
Annotations:  rbac.authorization.kubernetes.io/autoupdate: true
PolicyRule:
Resources  Non-Resource URLs  Resource Names  Verbs
---------  -----------------  --------------  -----
*.*        []                 []              [*]
[*]                []              [*]

controlplane ~ ➜

★ 새로운 사용자 미셸이 팀에 합류했습니다. 그녀가 노드에 액세스할 수 있도록 필요한 ClusterRoles 및 ClusterRoleBinding을 만듭니다.

-> 기존 cluster-admin 을 yaml 파일로 복사


controlplane ~ ➜ kubectl get clusterrole cluster-admin -o yaml > michelle.yaml
controlplane ~ ➜

-> 복사한 yaml 파일 확인


controlplane ~ ➜  cat michelle.yaml
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
annotations:
rbac.authorization.kubernetes.io/autoupdate: "true"
creationTimestamp: "2023-06-06T07:08:22Z"
labels:
kubernetes.io/bootstrapping: rbac-defaults
name: cluster-admin
resourceVersion: "68"
uid: 0d93b435-10ba-475e-ae77-d46510f93d75
rules:
- apiGroups:
- '*'
resources:
- '*'
verbs:
- '*'
- nonResourceURLs:
- '*'
verbs:
- '*'

-> 복사한 yaml 파일 수정


controlplane ~ ➜  cat michelle.yaml
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
name: node-admin
rules:
- apiGroups: [""]
resources: ["nodes"]
verbs: ["get", "watch", "list", "create", "delete"]

controlplane ~ ➜

-> 새로운 clusterrole 생성


controlplane ~ ➜  kubectl create -f michelle.yaml
clusterrole.rbac.authorization.k8s.io/node-admin created

controlplane ~ ➜

-> clusterrolebinding 복사


controlplane ~ ➜  kubectl get clusterrolebinding system:basic-user -o yaml > michelle-binding.yaml

controlplane ~ ➜

-> 내용 확인


controlplane ~ ➜  cat michelle-binding.yaml
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
annotations:
rbac.authorization.kubernetes.io/autoupdate: "true"
creationTimestamp: "2023-06-06T07:08:24Z"
labels:
kubernetes.io/bootstrapping: rbac-defaults
name: system:basic-user
resourceVersion: "138"
uid: 8ec82b9d-2758-4347-a0d2-25ac08eb17b6
roleRef:
apiGroup: rbac.authorization.k8s.io
kind: ClusterRole
name: system:basic-user
subjects:
- apiGroup: rbac.authorization.k8s.io
kind: Group
name: system:authenticated

controlplane ~ ➜

-> 내용 수정


controlplane ~ ➜  cat michelle-binding.yaml
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
name: michelle-binding
roleRef:
apiGroup: rbac.authorization.k8s.io
kind: ClusterRole
name: node-admin
subjects:
- apiGroup: rbac.authorization.k8s.io
kind: User
name: michelle

controlplane ~ ➜

-> clusterrolebinding 생성


controlplane ~ ➜  kubectl create -f michelle-binding.yaml
clusterrolebinding.rbac.authorization.k8s.io/michelle-binding created

controlplane ~ ➜

★ 미셸의 책임이 커지면서 이제 그녀는 스토리지도 담당하게 됩니다. 그녀가 스토리지에 액세스할 수 있도록 필요한 ClusterRoles과 clusterrolebinding을 생성한다.

-> stroage-admin 룰 생성


controlplane ~ ➜  kubectl create clusterrole storage-admin --resource=persistentvolumes,storageclasses --verb=get,list,create,delete,watch
clusterrole.rbac.authorization.k8s.io/storage-admin created

controlplane ~ ➜

-> 룰 확인


controlplane ~ ➜  kubectl describe clusterrole storage-admin
Name:         storage-admin
Labels:       <none>
Annotations:  <none>
PolicyRule:
Resources                      Non-Resource URLs  Resource Names  Verbs
---------                      -----------------  --------------  -----
persistentvolumes              []                 []              [get list create delete watch]
storageclasses.storage.k8s.io  []                 []              [get list create delete watch]

controlplane ~ ➜

-> michelle-stroage-admin 생성


controlplane ~ ➜  kubectl create clusterrolebinding michelle-storage-admin --user=michelle --clusterrole=storage-admin

clusterrolebinding.rbac.authorization.k8s.io/michelle-storage-admin created

controlplane ~ ➜

-> 룰 확인


controlplane ~ ➜  kubectl describe clusterrolebindings michelle-storage-admin
Name:         michelle-storage-admin
Labels:       <none>
Annotations:  <none>
Role:
Kind:  ClusterRole
Name:  storage-admin
Subjects:
Kind  Name      Namespace
----  ----      ---------
User  michelle

controlplane ~ ➜

저작자표시 (새창열림)

'Kubernetes > Kubernetes Exam' 카테고리의 다른 글

[K8s] CKA 취득 연습문제#8 (role, rolebinding) (0)	2023.06.06
[K8s] CKA 취득 연습문제#7 (kubeconfig view) (0)	2023.05.30
[K8s] CKA 취득 연습문제#6 (csr approve, reject) (0)	2023.05.30
[K8s] CKA 취득 연습문제#5 (etcd, apiserver 인증서) (0)	2023.05.29
[K8s] CKA 취득 연습문제#4 (etcd backup, recovery) (0)	2023.05.24

2023.06.06

★ kube-apiserver 클러스터에 구성된 인증 모드를 확인합니다.

-> Node, RBAC


controlplane ~ ➜ kubectl get pods -A
NAMESPACE      NAME                                   READY   STATUS    RESTARTS   AGE
blue           blue-app                               1/1     Running   0          3m50s
blue           dark-blue-app                          1/1     Running   0          3m50s
default        red-84c985b67c-ncs4w                   1/1     Running   0          3m51s
default        red-84c985b67c-whbgx                   1/1     Running   0          3m51s
kube-flannel   kube-flannel-ds-fmzvv                  1/1     Running   0          7m12s
kube-system    coredns-787d4945fb-p9td5               1/1     Running   0          7m11s
kube-system    coredns-787d4945fb-qqzl2               1/1     Running   0          7m12s
kube-system    etcd-controlplane                      1/1     Running   0          7m22s
kube-system    kube-apiserver-controlplane            1/1     Running   0          7m24s
kube-system    kube-controller-manager-controlplane   1/1     Running   0          7m27s
kube-system    kube-proxy-r8dbm                       1/1     Running   0          7m12s
kube-system    kube-scheduler-controlplane            1/1     Running   0          7m22s

controlplane ~ ➜
controlplane ~ ➜  kubectl describe pods -n kube-system kube-apiserver-controlplane | grep authorization
--authorization-mode=Node,RBAC

controlplane ~ ➜

★ default 네임스페이스에 몇개의 role이 존재하나요?.

-> 0


controlplane ~ ➜  kubectl get role -n default
No resources found in default namespace.

controlplane ~ ➜

★ 모든 네임스페이스에 총 몇 개의 role이 존재하나요?

-> 12


controlplane ~ ➜  kubectl get role -A
NAMESPACE     NAME                                             CREATED AT
blue          developer                                        2023-06-06T05:54:21Z
kube-public   kubeadm:bootstrap-signer-clusterinfo             2023-06-06T05:50:46Z
kube-public   system:controller:bootstrap-signer               2023-06-06T05:50:45Z
kube-system   extension-apiserver-authentication-reader        2023-06-06T05:50:44Z
kube-system   kube-proxy                                       2023-06-06T05:50:48Z
kube-system   kubeadm:kubelet-config                           2023-06-06T05:50:45Z
kube-system   kubeadm:nodes-kubeadm-config                     2023-06-06T05:50:45Z
kube-system   system::leader-locking-kube-controller-manager   2023-06-06T05:50:45Z
kube-system   system::leader-locking-kube-scheduler            2023-06-06T05:50:45Z
kube-system   system:controller:bootstrap-signer               2023-06-06T05:50:44Z
kube-system   system:controller:cloud-provider                 2023-06-06T05:50:44Z
kube-system   system:controller:token-cleaner                  2023-06-06T05:50:45Z

controlplane ~ ➜

★ kube-system 네임스페이스의 kube-proxy 역할에 액세스 권한이 부여된 리소스에는 어떤 것이 있나요?

-> configmaps


controlplane ~ ➜  kubectl describe role -n kube-system kube-proxy
Name:         kube-proxy
Labels:       <none>
Annotations:  <none>
PolicyRule:
Resources   Non-Resource URLs  Resource Names  Verbs
---------   -----------------  --------------  -----
configmaps  []                 [kube-proxy]    [get]

controlplane ~ ➜

★ kube-proxy role은 컨피그맵에서 어떤 권한을 수행할 수 있나요?

-> get

-> kube-proxy 역할은 kube-proxy라는 이름으로만 컨피그맵 오브젝트의 세부 정보를 가져올 수 있다.


controlplane ~ ➜  kubectl describe role -n kube-system kube-proxy
Name:         kube-proxy
Labels:       <none>
Annotations:  <none>
PolicyRule:
Resources   Non-Resource URLs  Resource Names  Verbs
---------   -----------------  --------------  -----
configmaps  []                 [kube-proxy]    [get]

controlplane ~ ➜

★ 어떤 계정에 kube-proxy 역할이 할당되나요?

-> Group:system:bootstrappers:kubeadm:default-node-token


controlplane ~ ➜  kubectl describe rolebindings -n kube-system kube-proxy
Name:         kube-proxy
Labels:       <none>
Annotations:  <none>
Role:
Kind:  Role
Name:  kube-proxy
Subjects:
Kind   Name                                             Namespace
----   ----                                             ---------
Group  system:bootstrappers:kubeadm:default-node-token

controlplane ~ ➜

★ 개발 사용자가 기본 네임스페이스에서 파드를 생성, 나열 및 삭제하는 데 필요한 role과 rolebinding을 생성합니다.

-> role 생성


controlplane ~ ➜  kubectl create role developer --namespace=default --verb=list,create,delete --resource=pods
role.rbac.authorization.k8s.io/developer created

controlplane ~ ➜

-> role binding 생성


controlplane ~ ➜  kubectl create rolebinding dev-user-binding --namespace=default --role=developer --user=dev-user
rolebinding.rbac.authorization.k8s.io/dev-user-binding created

controlplane ~ ➜

-> 생성 확인


controlplane ~ ➜  kubectl get role
NAME        CREATED AT
developer   2023-06-06T06:23:29Z

controlplane ~ ➜
controlplane ~ ➜  kubectl get rolebindings
NAME               ROLE             AGE
dev-user-binding   Role/developer   63s

controlplane ~ ➜

-> 상세확인


controlplane ~ ➜  kubectl describe role developer
Name:         developer
Labels:       <none>
Annotations:  <none>
PolicyRule:
Resources  Non-Resource URLs  Resource Names  Verbs
---------  -----------------  --------------  -----
pods       []                 []              [list create delete]

controlplane ~ ➜
controlplane ~ ➜  kubectl describe rolebindings dev-user-binding
Name:         dev-user-binding
Labels:       <none>
Annotations:  <none>
Role:
Kind:  Role
Name:  developer
Subjects:
Kind  Name      Namespace
----  ----      ---------
User  dev-user

controlplane ~ ➜

★ dark-blue-app 파드에 developer role을 연동해주세요.

-> 기존에는 Resource Names에 blue-app으로 연동되어있는데 바꿔줘야한다.


controlplane ~ ➜  kubectl describe role -n blue developer
Name:         developer
Labels:       <none>
Annotations:  <none>
PolicyRule:
Resources  Non-Resource URLs  Resource Names  Verbs
---------  -----------------  --------------  -----
pods       []                 [blue-app]      [get watch create delete]

controlplane ~ ➜

-> 파드 이름을 수정


apiVersion: rbac.authorization.k8s.io/v1
kind: Role
metadata:
creationTimestamp: "2023-06-06T05:54:21Z"
name: developer
namespace: blue
resourceVersion: "3780"
uid: cf0b171d-870f-4cf8-a585-33d9294ccf95
rules:
- apiGroups:
- ""
resourceNames:
- dark-blue-app
resources:
- pods
verbs:
- get
- watch
- create
- delete

-> 확인


controlplane ~ ➜  kubectl edit role -n blue developer
role.rbac.authorization.k8s.io/developer edited

controlplane ~ ➜

controlplane ~ ➜

controlplane ~ ➜  kubectl describe role -n blue
Name:         developer
Labels:       <none>
Annotations:  <none>
PolicyRule:
Resources  Non-Resource URLs  Resource Names   Verbs
---------  -----------------  --------------   -----
pods       []                 [dark-blue-app]  [get watch create delete]

controlplane ~ ➜

★ 기존 developer 새 규칙을 추가하여 blue 네임스페이스에서 배포를 만들 수 있는 dev-user 권한을 부여합니다.

-> 기존 role에서 아래 apiGroups 부터 추가 기입


apiVersion: rbac.authorization.k8s.io/v1
kind: Role
metadata:
creationTimestamp: "2023-06-06T05:54:21Z"
name: developer
namespace: blue
resourceVersion: "4827"
uid: cf0b171d-870f-4cf8-a585-33d9294ccf95
rules:
- apiGroups:
- apps
resourceNames:
- dark-blue-app
resources:
- pods
verbs:
- get
- watch
- create
- delete
- apiGroups:
- apps
resources:
- deployments
verbs:
- create

-> edit 완료


controlplane ~ ➜  kubectl edit role -n blue developer
role.rbac.authorization.k8s.io/developer edited

controlplane ~ ➜

- role 상세 확인


controlplane ~ ➜  kubectl describe role -n blue developer
Name:         developer
Labels:       <none>
Annotations:  <none>
PolicyRule:
Resources         Non-Resource URLs  Resource Names   Verbs
---------         -----------------  --------------   -----
deployments.apps  []                 []               [create]
pods.apps         []                 [dark-blue-app]  [get watch create delete]

controlplane ~ ➜

저작자표시 (새창열림)

'Kubernetes > Kubernetes Exam' 카테고리의 다른 글

[K8s] CKA 취득 연습문제#9 (clusterrole, clusterrolebinding) (0)	2023.06.06
[K8s] CKA 취득 연습문제#7 (kubeconfig view) (0)	2023.05.30
[K8s] CKA 취득 연습문제#6 (csr approve, reject) (0)	2023.05.30
[K8s] CKA 취득 연습문제#5 (etcd, apiserver 인증서) (0)	2023.05.29
[K8s] CKA 취득 연습문제#4 (etcd backup, recovery) (0)	2023.05.24

2023.05.30

★ kubeconfig 파일에 몇 개의 클러스터가 정의되어 있는가?

-> 1개


controlplane ~ ➜ kubectl config view
apiVersion: v1
clusters:
- cluster:
certificate-authority-data: DATA+OMITTED
server: https://controlplane:6443
name: kubernetes
contexts:
- context:
cluster: kubernetes
user: kubernetes-admin
name: kubernetes-admin@kubernetes
current-context: kubernetes-admin@kubernetes
kind: Config
preferences: {}
users:
- name: kubernetes-admin
user:
client-certificate-data: DATA+OMITTED
client-key-data: DATA+OMITTED

controlplane ~ ➜

★ kubeconfig 파일에 몇명의 사용자가 정의되어 있는가?

-> 1명


controlplane ~ ➜  kubectl config view
apiVersion: v1
clusters:
- cluster:
certificate-authority-data: DATA+OMITTED
server: https://controlplane:6443
name: kubernetes
contexts:
- context:
cluster: kubernetes
user: kubernetes-admin
name: kubernetes-admin@kubernetes
current-context: kubernetes-admin@kubernetes
kind: Config
preferences: {}
users:
- name: kubernetes-admin
user:
client-certificate-data: DATA+OMITTED
client-key-data: DATA+OMITTED

controlplane ~ ➜

★ kubeconfig 파일에는 몇 개의 컨텍스트가 정의되어 있는가?

-> 1개


controlplane ~ ➜  kubectl config view
apiVersion: v1
clusters:
- cluster:
certificate-authority-data: DATA+OMITTED
server: https://controlplane:6443
name: kubernetes
contexts:
- context:
cluster: kubernetes
user: kubernetes-admin
name: kubernetes-admin@kubernetes
current-context: kubernetes-admin@kubernetes
kind: Config
preferences: {}
users:
- name: kubernetes-admin
user:
client-certificate-data: DATA+OMITTED
client-key-data: DATA+OMITTED

controlplane ~ ➜

★ 컨텍스트에서 구성된 사용자 이름이 무엇인가요?

-> kubernetes-admin


controlplane ~ ➜  kubectl config view
apiVersion: v1
clusters:
- cluster:
certificate-authority-data: DATA+OMITTED
server: https://controlplane:6443
name: kubernetes
contexts:
- context:
cluster: kubernetes
user: kubernetes-admin
name: kubernetes-admin@kubernetes
current-context: kubernetes-admin@kubernetes
kind: Config
preferences: {}
users:
- name: kubernetes-admin
user:
client-certificate-data: DATA+OMITTED
client-key-data: DATA+OMITTED

controlplane ~ ➜

★ 컨텍스트에서 구성된 클러스터 이름이 무엇인가요?

-> kubernetes


controlplane ~ ➜  kubectl config view
apiVersion: v1
clusters:
- cluster:
certificate-authority-data: DATA+OMITTED
server: https://controlplane:6443
name: kubernetes
contexts:
- context:
cluster: kubernetes
user: kubernetes-admin
name: kubernetes-admin@kubernetes
current-context: kubernetes-admin@kubernetes
kind: Config
preferences: {}
users:
- name: kubernetes-admin
user:
client-certificate-data: DATA+OMITTED
client-key-data: DATA+OMITTED

controlplane ~ ➜

★ my-kube-config 구성된 클러스터는 몇개인가요?

-> 4개

★ my-kube-config 구성된 컨텍스트는 몇개인가요?

-> 4개

★ my-kube-config 구성된 컨텍스트에서 research의 유저는 누구인가요?

-> dev-user

★ my-kube-config 구성된 aws-user의 인증서 파일명은 무엇인가요?

-> aws-user.crt


controlplane ~ ➜  kubectl config view --kubeconfig my-kube-config
apiVersion: v1
clusters:
- cluster:
certificate-authority: /etc/kubernetes/pki/ca.crt
server: https://controlplane:6443
name: development
- cluster:
certificate-authority: /etc/kubernetes/pki/ca.crt
server: https://controlplane:6443
name: kubernetes-on-aws
- cluster:
certificate-authority: /etc/kubernetes/pki/ca.crt
server: https://controlplane:6443
name: production
- cluster:
certificate-authority: /etc/kubernetes/pki/ca.crt
server: https://controlplane:6443
name: test-cluster-1
contexts:
- context:
cluster: kubernetes-on-aws
user: aws-user
name: aws-user@kubernetes-on-aws
- context:
cluster: test-cluster-1
user: dev-user
name: research
- context:
cluster: development
user: test-user
name: test-user@development
- context:
cluster: production
user: test-user
name: test-user@production
current-context: test-user@development
kind: Config
preferences: {}
users:
- name: aws-user
user:
client-certificate: /etc/kubernetes/pki/users/aws-user/aws-user.crt
client-key: /etc/kubernetes/pki/users/aws-user/aws-user.key
- name: dev-user
user:
client-certificate: /etc/kubernetes/pki/users/dev-user/developer-user.crt
client-key: /etc/kubernetes/pki/users/dev-user/dev-user.key
- name: test-user
user:
client-certificate: /etc/kubernetes/pki/users/test-user/test-user.crt
client-key: /etc/kubernetes/pki/users/test-user/test-user.key

controlplane ~ ➜

★ my-kube-config 파일에서 현재 컨텍스트가 무엇으로 설정되어 있나요?

-> test-user@development


controlplane ~ ➜  kubectl config current-context --kubeconfig my-kube-config
test-user@development

controlplane ~ ➜

★ dev-user를 사용하여 test-cluster-1에 접근하려고합니다. 현재 컨텍스트를 올바른 컨텍스트로 설정해주세요.

-> research 컨텍스트로 스위칭


controlplane ~ ➜  kubectl config --kubeconfig=/root/my-kube-config use-context research
Switched to context "research".

controlplane ~ ➜

-> 현재 컨텍스트 확인


controlplane ~ ➜  kubectl config --kubeconfig=/root/my-kube-config current-context
research

controlplane ~ ➜

★ my-kube-config 파일을 기본 kubeconfig로 설정한다.

-> /.kube/config 파일에다가 복사한다.


controlplane  ➜  mv my-kube-config /root/.kube/config

-> 확인한다.


controlplane ~ ➜  kubectl config view
apiVersion: v1
clusters:
- cluster:
certificate-authority: /etc/kubernetes/pki/ca.crt
server: https://controlplane:6443
name: development
- cluster:
certificate-authority: /etc/kubernetes/pki/ca.crt
server: https://controlplane:6443
name: kubernetes-on-aws
- cluster:
certificate-authority: /etc/kubernetes/pki/ca.crt
server: https://controlplane:6443
name: production
- cluster:
certificate-authority: /etc/kubernetes/pki/ca.crt
server: https://controlplane:6443
name: test-cluster-1
contexts:
- context:
cluster: kubernetes-on-aws
user: aws-user
name: aws-user@kubernetes-on-aws
- context:
cluster: test-cluster-1
user: dev-user
name: research
- context:
cluster: development
user: test-user
name: test-user@development
- context:
cluster: production
user: test-user
name: test-user@production
current-context: research
kind: Config
preferences: {}
users:
- name: aws-user
user:
client-certificate: /etc/kubernetes/pki/users/aws-user/aws-user.crt
client-key: /etc/kubernetes/pki/users/aws-user/aws-user.key
- name: dev-user
user:
client-certificate: /etc/kubernetes/pki/users/dev-user/developer-user.crt
client-key: /etc/kubernetes/pki/users/dev-user/dev-user.key
- name: test-user
user:
client-certificate: /etc/kubernetes/pki/users/test-user/test-user.crt
client-key: /etc/kubernetes/pki/users/test-user/test-user.key

controlplane ~ ➜

★ 현재 컨텍스트를 연구로 설정한 상태에서 클러스터에 액세스하려고 합니다. 그러나 뭔가 잘못된 것 같습니다. 문제를 식별하고 수정하세요.

-> pod를 확인하려는데 오류 발생 (사용자 인증서를 읽을 수 없음)


controlplane ~ ➜  kubectl get pods
error: unable to read client-cert /etc/kubernetes/pki/users/dev-user/developer-user.crt for dev-user due to open /etc/kubernetes/pki/users/dev-user/developer-user.crt: no such file or directory

controlplane ~ ✖

-> config를 보고 user항목에 키 경로 확인해보기


controlplane ~ ✖ kubectl config view
users:
- name: aws-user
user:
client-certificate: /etc/kubernetes/pki/users/aws-user/aws-user.crt
client-key: /etc/kubernetes/pki/users/aws-user/aws-user.key
- name: dev-user
user:
client-certificate: /etc/kubernetes/pki/users/dev-user/developer-user.crt
client-key: /etc/kubernetes/pki/users/dev-user/dev-user.key
- name: test-user
user:
client-certificate: /etc/kubernetes/pki/users/test-user/test-user.crt
client-key: /etc/kubernetes/pki/users/test-user/test-user.key

controlplane ~ ➜

-> client-certificate: /etc/kubernetes/pki/users/dev-user/developer-user.crt 고치기


controlplane ~ ➜ kubectl config view

users:
- name: aws-user
user:
client-certificate: /etc/kubernetes/pki/users/aws-user/aws-user.crt
client-key: /etc/kubernetes/pki/users/aws-user/aws-user.key
- name: dev-user
user:
client-certificate: /etc/kubernetes/pki/users/dev-user/dev-user.crt
client-key: /etc/kubernetes/pki/users/dev-user/dev-user.key
- name: test-user
user:
client-certificate: /etc/kubernetes/pki/users/test-user/test-user.crt
client-key: /etc/kubernetes/pki/users/test-user/test-user.key

controlplane ~ ➜

-> pod 확인


controlplane ~ ➜  kubectl get pods -A
NAMESPACE      NAME                                   READY   STATUS    RESTARTS   AGE
kube-flannel   kube-flannel-ds-2mr4z                  1/1     Running   0          54m
kube-system    coredns-787d4945fb-bxctq               1/1     Running   0          54m
kube-system    coredns-787d4945fb-r7hz5               1/1     Running   0          54m
kube-system    etcd-controlplane                      1/1     Running   0          54m
kube-system    kube-apiserver-controlplane            1/1     Running   0          54m
kube-system    kube-controller-manager-controlplane   1/1     Running   0          54m
kube-system    kube-proxy-f27wr                       1/1     Running   0          54m
kube-system    kube-scheduler-controlplane            1/1     Running   0          54m

controlplane ~ ➜

저작자표시 (새창열림)

'Kubernetes > Kubernetes Exam' 카테고리의 다른 글

[K8s] CKA 취득 연습문제#9 (clusterrole, clusterrolebinding) (0)	2023.06.06
[K8s] CKA 취득 연습문제#8 (role, rolebinding) (0)	2023.06.06
[K8s] CKA 취득 연습문제#6 (csr approve, reject) (0)	2023.05.30
[K8s] CKA 취득 연습문제#5 (etcd, apiserver 인증서) (0)	2023.05.29
[K8s] CKA 취득 연습문제#4 (etcd backup, recovery) (0)	2023.05.24

2023.05.30

★ 새로운 사람이 들어왔다. 그사람을 cluster에 접속할 수 있게 akshay.csr 파일의 내용을 사용하여 이름이 akshay인 CertificateSigningRequest 오브젝트를 생성해보자.

-> 해당 인증서를 base64 값으로 출력한다.


controlplane ~ ➜  cat akshay.csr | base64 -w 0
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
controlplane ~ ➜

-> 출력한 키값을 yaml 파일을 만들어서 저장한다.


controlplane ~ ➜  vi akshay-csr.yaml

controlplane ~ ➜  cat akshay-csr.yaml
---
apiVersion: certificates.k8s.io/v1
kind: CertificateSigningRequest
metadata:
name: akshay
spec:
groups:
- system:authenticated
request: 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
signerName: kubernetes.io/kube-apiserver-client
usages:
- client auth

controlplane ~ ➜

-> 저장한 yaml 파일을 생성한다.


controlplane ~ ➜  kubectl apply -f akshay-csr.yaml
certificatesigningrequest.certificates.k8s.io/akshay created

controlplane ~ ➜

★ 새로 만든 인증서 서명 요청 개체의 상태는 어떤인가요?

-> Pending


controlplane ~ ➜  kubectl get csr
NAME        AGE    SIGNERNAME                                    REQUESTOR                  REQUESTEDDURATION   CONDITION
akshay      118s   kubernetes.io/kube-apiserver-client           kubernetes-admin           <none>              Pending
csr-gwpnt   18m    kubernetes.io/kube-apiserver-client-kubelet   system:node:controlplane   <none>              Approved,Issued

controlplane ~ ➜

★ CSR 요청을 승인해 주세요.


controlplane ~ ➜  kubectl certificate approve akshay
certificatesigningrequest.certificates.k8s.io/akshay approved

controlplane ~ ➜
controlplane ~ ➜  kubectl get csr
NAME        AGE     SIGNERNAME                                    REQUESTOR                  REQUESTEDDURATION   CONDITION
akshay      4m19s   kubernetes.io/kube-apiserver-client           kubernetes-admin           <none>              Approved,Issued
csr-gwpnt   20m     kubernetes.io/kube-apiserver-client-kubelet   system:node:controlplane   <none>              Approved,Issued

controlplane ~ ➜

★ CSR 승인요청이 왔습니다. 어떤 그룹에 대한 액세스를 요청하는 CSR인가요?

-> 이름 : agent-smith


controlplane ~ ➜  kubectl get csr
NAME          AGE     SIGNERNAME                                    REQUESTOR                  REQUESTEDDURATION   CONDITION
agent-smith   15s     kubernetes.io/kube-apiserver-client           agent-x                    <none>              Pending
akshay        5m35s   kubernetes.io/kube-apiserver-client           kubernetes-admin           <none>              Approved,Issued
csr-gwpnt     21m     kubernetes.io/kube-apiserver-client-kubelet   system:node:controlplane   <none>              Approved,Issued

controlplane ~ ➜

-> 그룹 : system:masters


controlplane ~ ➜  kubectl get csr agent-smith -o yaml
apiVersion: certificates.k8s.io/v1
kind: CertificateSigningRequest
metadata:
creationTimestamp: "2023-05-30T13:13:51Z"
name: agent-smith
resourceVersion: "2115"
uid: b1aad5d7-ec17-468a-b157-b36bf328ed60
spec:
groups:
- system:masters
- system:authenticated
request: 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
signerName: kubernetes.io/kube-apiserver-client
usages:
- digital signature
- key encipherment
- server auth
username: agent-x
status: {}

controlplane ~ ➜

★ CSR 승인을 거절하세요.

-> kubectl certificate deny agent-smith


controlplane ~ ➜  kubectl certificate deny agent-smith
certificatesigningrequest.certificates.k8s.io/agent-smith denied

controlplane ~ ➜  kubectl get csr
NAME          AGE     SIGNERNAME                                    REQUESTOR                  REQUESTEDDURATION   CONDITION
agent-smith   6m21s   kubernetes.io/kube-apiserver-client           agent-x                    <none>              Denied
akshay        11m     kubernetes.io/kube-apiserver-client           kubernetes-admin           <none>              Approved,Issued
csr-gwpnt     27m     kubernetes.io/kube-apiserver-client-kubelet   system:node:controlplane   <none>              Approved,Issued

controlplane ~ ➜

★ CSR 요청을 삭제하세요.

-> kubectl delete csr agent-smith


controlplane ~ ➜  kubectl delete csr agent-smith
certificatesigningrequest.certificates.k8s.io "agent-smith" deleted

controlplane ~ ➜  kubectl get csr
NAME        AGE   SIGNERNAME                                    REQUESTOR                  REQUESTEDDURATION   CONDITION
akshay      13m   kubernetes.io/kube-apiserver-client           kubernetes-admin           <none>              Approved,Issued
csr-gwpnt   29m   kubernetes.io/kube-apiserver-client-kubelet   system:node:controlplane   <none>              Approved,Issued

controlplane ~ ➜

저작자표시 (새창열림)

'Kubernetes > Kubernetes Exam' 카테고리의 다른 글

[K8s] CKA 취득 연습문제#8 (role, rolebinding) (0)	2023.06.06
[K8s] CKA 취득 연습문제#7 (kubeconfig view) (0)	2023.05.30
[K8s] CKA 취득 연습문제#5 (etcd, apiserver 인증서) (0)	2023.05.29
[K8s] CKA 취득 연습문제#4 (etcd backup, recovery) (0)	2023.05.24
[K8s] CKA 취득 연습문제#3 (etcd backup, snapshot) (0)	2023.05.20

2023.05.29

★ kube-apiserver에서 사용하고 있는 인증서 파일 위치 확인

1. kube-apiserver.yaml 파일 확인

-> --tls-cert-file=/etc/kubernetes/pki/apiserver.crt


controlplane ~ ➜ cat /etc/kubernetes/manifests/kube-apiserver.yaml | grep tls
- --tls-cert-file=/etc/kubernetes/pki/apiserver.crt
- --tls-private-key-file=/etc/kubernetes/pki/apiserver.key

controlplane ~ ➜

2. kube-apiserver pod 확인

-> --tls-cert-file=/etc/kubernetes/pki/apiserver.crt


controlplane ~ ➜  kubectl -n kube-system describe pods kube-apiserver-controlplane | grep tls
--tls-cert-file=/etc/kubernetes/pki/apiserver.crt
--tls-private-key-file=/etc/kubernetes/pki/apiserver.key

controlplane ~ ➜

★ kube-apiserver에서 사용하고 있는 etcd-client 인증서 파일 위치 확인

-> etcd-certfile=/etc/kubernetes/pki/apiserver-etcd-client.crt


controlplane ~ ➜  cat /etc/kubernetes/manifests/kube-apiserver.yaml | grep etcd
- --etcd-cafile=/etc/kubernetes/pki/etcd/ca.crt
- --etcd-certfile=/etc/kubernetes/pki/apiserver-etcd-client.crt
- --etcd-keyfile=/etc/kubernetes/pki/apiserver-etcd-client.key
- --etcd-servers=https://127.0.0.1:2379

controlplane ~ ➜

★ kube-apiserver에서 사용하고 있는 kubelet 키 파일 위치 확인

-> --kubelet-client-key=/etc/kubernetes/pki/apiserver-kubelet-client.key


controlplane ~ ➜  cat /etc/kubernetes/manifests/kube-apiserver.yaml | grep kubelet
- --kubelet-client-certificate=/etc/kubernetes/pki/apiserver-kubelet-client.crt
- --kubelet-client-key=/etc/kubernetes/pki/apiserver-kubelet-client.key
- --kubelet-preferred-address-types=InternalIP,ExternalIP,Hostname

controlplane ~ ➜

★ etcd server 에서 사용하고 있는 인증서 파일 위치 확인

-> --cert-file=/etc/kubernetes/pki/etcd/server.crt


controlplane ~ ➜  cat /etc/kubernetes/manifests/etcd.yaml | grep cert
- --cert-file=/etc/kubernetes/pki/etcd/server.crt
- --client-cert-auth=true
- --peer-cert-file=/etc/kubernetes/pki/etcd/peer.crt
- --peer-client-cert-auth=true
name: etcd-certs
name: etcd-certs

controlplane ~ ➜

★ etcd server 에서 사용하고 있는 자체 ca 인증서 파일 위치 확인

-> --trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt


controlplane ~ ➜  cat /etc/kubernetes/manifests/etcd.yaml | grep ca
- --peer-trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt
- --trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt
priorityClassName: system-node-critical

controlplane ~ ➜

★ Kube-apiserver 인증서에 구성된 CN 이름은 무엇인가요?

-> Subject: CN = kube-apiserver


controlplane ~ ➜  openssl x509 -in /etc/kubernetes/pki/apiserver.crt -text
Certificate:
Data:
Version: 3 (0x2)
Serial Number: 8483000120492181273 (0x75b9abaa2b884719)
Signature Algorithm: sha256WithRSAEncryption
Issuer: CN = kubernetes
Validity
Not Before: May 29 11:43:33 2023 GMT
Not After : May 28 11:43:33 2024 GMT
Subject: CN = kube-apiserver
Subject Public Key Info:
Public Key Algorithm: rsaEncryption
RSA Public-Key: (2048 bit)
...

★ Kube-apiserver 인증서를 발급한 CA의 이름은 무엇인가요?

-> Issuer: CN = kubernetes


controlplane ~ ➜  openssl x509 -in /etc/kubernetes/pki/apiserver.crt -text
Certificate:
Data:
Version: 3 (0x2)
Serial Number: 8483000120492181273 (0x75b9abaa2b884719)
Signature Algorithm: sha256WithRSAEncryption
Issuer: CN = kubernetes
Validity
Not Before: May 29 11:43:33 2023 GMT
Not After : May 28 11:43:33 2024 GMT
Subject: CN = kube-apiserver
Subject Public Key Info:
Public Key Algorithm: rsaEncryption
RSA Public-Key: (2048 bit)
...

★ Kube-apiserver 인증서에 구성된 대체 이름은 무엇인가요?

-> DNS:controlplane, DNS:kubernetes, DNS:kubernetes.default, DNS:kubernetes.default.svc, DNS:kubernetes.default.svc.cluster.local, IP Address:10.96.0.1, IP Address:192.26.249.9


controlplane ~ ➜  openssl x509 -in /etc/kubernetes/pki/apiserver.crt -text
Certificate:
Data:
Version: 3 (0x2)
Serial Number: 8483000120492181273 (0x75b9abaa2b884719)
Signature Algorithm: sha256WithRSAEncryption
Issuer: CN = kubernetes
Validity
Not Before: May 29 11:43:33 2023 GMT
Not After : May 28 11:43:33 2024 GMT
Subject: CN = kube-apiserver
Subject Public Key Info:
Public Key Algorithm: rsaEncryption
RSA Public-Key: (2048 bit)
Modulus:
00:a3:2f:ff:75:ed:b2:38:74:01:f9:b1:41:51:aa:
f5:bb:9a:39:02:46:c2:5b:05:b1:0e:8f:75:9b:46:
18:a5:35:52:2f:2d:22:3b:fe:37:e3:ea:98:32:c5:
79:b4:2d:1b:f2:67:cd:f6:7d:4e:fa:e8:a0:69:b4:
4b:c8:25:46:20:4b:ad:69:dd:fa:63:56:b4:5c:4f:
ce:b7:28:bb:43:de:59:5f:c6:e7:c7:16:08:11:cf:
28:b2:4a:7f:20:74:3d:f4:53:6a:b6:33:37:25:98:
3e:a7:02:56:da:1b:75:7a:39:bd:0a:31:d5:26:cb:
30:8b:3d:bf:a5:58:48:8c:a8:5d:b4:eb:51:0d:72:
52:32:85:60:0d:56:2f:46:3c:65:90:4a:9b:a3:01:
b3:d9:01:b2:d9:ea:70:68:38:49:d5:1a:29:9f:52:
b8:54:72:71:0c:4a:88:4b:73:63:6f:05:a0:b6:23:
03:31:12:be:c3:cf:6c:b7:2b:e6:4e:50:a1:1b:7f:
ab:2a:ba:5f:92:16:3d:4c:ac:d8:02:11:78:8b:bf:
4e:43:3b:e5:0c:57:fb:6f:8a:81:ef:51:7e:a3:92:
2a:de:2b:96:ae:95:2e:dc:e3:97:ce:c7:af:8d:42:
67:2c:6a:3a:fa:fa:67:79:d2:14:52:47:eb:65:ca:
53:af
Exponent: 65537 (0x10001)
X509v3 extensions:
X509v3 Key Usage: critical
Digital Signature, Key Encipherment
X509v3 Extended Key Usage:
TLS Web Server Authentication
X509v3 Basic Constraints: critical
CA:FALSE
X509v3 Authority Key Identifier:
keyid:AB:7D:E2:A1:2C:F0:E0:27:53:52:72:D8:C9:46:76:09:F8:77:0D:63

X509v3 Subject Alternative Name:
DNS:controlplane, DNS:kubernetes, DNS:kubernetes.default, DNS:kubernetes.default.svc, DNS:kubernetes.default.svc.cluster.local, IP Address:10.96.0.1, IP Address:192.26.249.9

★ etcd server 인증서에 구성된 CN은 무엇인가요?

-> Subject: CN = controlplane


controlplane ~ ➜  openssl x509 -in /etc/kubernetes/pki/etcd/server.crt -text
Certificate:
Data:
Version: 3 (0x2)
Serial Number: 253720388574558331 (0x38565596142b87b)
Signature Algorithm: sha256WithRSAEncryption
Issuer: CN = etcd-ca
Validity
Not Before: May 29 11:43:34 2023 GMT
Not After : May 28 11:43:34 2024 GMT
Subject: CN = controlplane
Subject Public Key Info:
Public Key Algorithm: rsaEncryption
RSA Public-Key: (2048 bit)
...

★ etcd server 인증서는 발급일로부터 얼마 동안 유효하나요?

-> 1 years


controlplane ~ ➜  openssl x509 -in /etc/kubernetes/pki/etcd/server.crt -text
Certificate:
Data:
Version: 3 (0x2)
Serial Number: 253720388574558331 (0x38565596142b87b)
Signature Algorithm: sha256WithRSAEncryption
Issuer: CN = etcd-ca
Validity
Not Before: May 29 11:43:34 2023 GMT
Not After : May 28 11:43:34 2024 GMT
Subject: CN = controlplane
Subject Public Key Info:
Public Key Algorithm: rsaEncryption
RSA Public-Key: (2048 bit)
...

★ etcd server ca인증서는 발급일로부터 얼마 동안 유효하나요?

-> 10 years


controlplane ~ ➜  openssl x509 -in /etc/kubernetes/pki/ca.crt -text
Certificate:
Data:
Version: 3 (0x2)
Serial Number: 0 (0x0)
Signature Algorithm: sha256WithRSAEncryption
Issuer: CN = kubernetes
Validity
Not Before: May 29 11:43:33 2023 GMT
Not After : May 26 11:43:33 2033 GMT
Subject: CN = kubernetes
Subject Public Key Info:
Public Key Algorithm: rsaEncryption
RSA Public-Key: (2048 bit)
...

★ kubectl 명령어가 동작하지 않습니다. etcd server를 확인해보고 틀린부분을 수정하시오.

-> etcd 서버 yaml 파일을 확인해보면 cert-file 경로에 server-certificate.crt 파일이라고 저장되어있다.


controlplane ~ ➜  cat /etc/kubernetes/manifests/etcd.yaml | grep cert-file
- --cert-file=/etc/kubernetes/pki/etcd/server-certificate.crt
- --peer-cert-file=/etc/kubernetes/pki/etcd/peer.crt

controlplane ~ ➜

-> 해당 경로에 crt 파일을 확인해보면 파일명이 다른걸 확인할 수 있다.


controlplane ~ ➜  ls /etc/kubernetes/pki/etcd/server* | grep .crt
/etc/kubernetes/pki/etcd/server.crt

controlplane ~ ➜

-> 경로명을 수정해주고 기다리면 api-server가 정상적으로 작동한다.


controlplane ~ ➜  vi /etc/kubernetes/manifests/etcd.yaml

controlplane ~ ➜  cat /etc/kubernetes/manifests/etcd.yaml | grep cert-file
- --cert-file=/etc/kubernetes/pki/etcd/server.crt
- --peer-cert-file=/etc/kubernetes/pki/etcd/peer.crt

controlplane ~ ➜

★ kubectl 명령어가 동작하지 않습니다. apiserver 서버의 logs를 확인해서 문제를 해결하시오.

-> crictl ps -a | grep kube-apiserver 명령어로 pod 상태 확인


controlplane ~ ➜  crictl ps -a | grep kube-apiserver
9bd19c0102ca6       a31e1d84401e6       36 seconds ago      Exited              kube-apiserver            5                   5413bff6f15be       kube-apiserver-controlplane

controlplane ~ ➜

-> logs를 확인해보니 etcd ca 인증서에 문제가 있는 것을 확인했습니다.


controlplane ~ ➜  crictl logs --tail=5 9bd19c0102ca6
"BalancerAttributes": null,
"Type": 0,
"Metadata": null
}. Err: connection error: desc = "transport: authentication handshake failed: x509: certificate signed by unknown authority"
E0529 13:03:01.408411       1 run.go:74] "command failed" err="context deadline exceeded"

controlplane ~ ➜

-> kube-apiserver.yaml 파일의 etcd cafile 위치가 잘못되어있습니다. 수정해주세요.


controlplane ~ ➜  cat /etc/kubernetes/manifests/kube-apiserver.yaml | grep etcd
- --etcd-cafile=/etc/kubernetes/pki/ca.crt
- --etcd-certfile=/etc/kubernetes/pki/apiserver-etcd-client.crt
- --etcd-keyfile=/etc/kubernetes/pki/apiserver-etcd-client.key
- --etcd-servers=https://127.0.0.1:2379

controlplane ~ ➜  cd /etc/kubernetes/pki/etcd/

controlplane kubernetes/pki/etcd ➜  ls -al
total 40
drwxr-xr-x 2 root root 4096 May 29 08:44 .
drwxr-xr-x 3 root root 4096 May 29 08:44 ..
-rw-r--r-- 1 root root 1086 May 29 08:44 ca.crt
-rw------- 1 root root 1675 May 29 08:44 ca.key
-rw-r--r-- 1 root root 1159 May 29 08:44 healthcheck-client.crt
-rw------- 1 root root 1679 May 29 08:44 healthcheck-client.key
-rw-r--r-- 1 root root 1208 May 29 08:44 peer.crt
-rw------- 1 root root 1679 May 29 08:44 peer.key
-rw-r--r-- 1 root root 1208 May 29 08:44 server.crt
-rw------- 1 root root 1675 May 29 08:44 server.key

controlplane kubernetes/pki/etcd ➜

-> --etcd-cafile=/etc/kubernetes/pki/etcd/ca.crt


controlplane ~ ➜  cat /etc/kubernetes/manifests/kube-apiserver.yaml | grep etcd
- --etcd-cafile=/etc/kubernetes/pki/etcd/ca.crt
- --etcd-certfile=/etc/kubernetes/pki/apiserver-etcd-client.crt
- --etcd-keyfile=/etc/kubernetes/pki/apiserver-etcd-client.key
- --etcd-servers=https://127.0.0.1:2379

controlplane ~ ➜

저작자표시 (새창열림)

'Kubernetes > Kubernetes Exam' 카테고리의 다른 글

[K8s] CKA 취득 연습문제#7 (kubeconfig view) (0)	2023.05.30
[K8s] CKA 취득 연습문제#6 (csr approve, reject) (0)	2023.05.30
[K8s] CKA 취득 연습문제#4 (etcd backup, recovery) (0)	2023.05.24
[K8s] CKA 취득 연습문제#3 (etcd backup, snapshot) (0)	2023.05.20
[K8s] CKA 취득 연습문제#2 (node upgrade) (0)	2023.05.17

2023.05.24

★ 여러개의 Cluster가 존재한다. 그 안에 node가 몇개인지 확인하시오.

> 클러스터 총 2개


student-node ~ ➜  kubectl config view
apiVersion: v1
clusters:
- cluster:
certificate-authority-data: DATA+OMITTED
server: https://cluster1-controlplane:6443
name: cluster1
- cluster:
certificate-authority-data: DATA+OMITTED
server: https://192.12.169.3:6443
name: cluster2
contexts:
- context:
cluster: cluster1
user: cluster1
name: cluster1
- context:
cluster: cluster2
user: cluster2
name: cluster2
current-context: cluster1
kind: Config
preferences: {}
users:
- name: cluster1
user:
client-certificate-data: REDACTED
client-key-data: REDACTED
- name: cluster2
user:
client-certificate-data: REDACTED
client-key-data: REDACTED

student-node ~ ➜

student-node ~ ➜ kubectl config use-context cluster
cluster1  cluster2

student-node ~ ➜ kubectl config use-context cluster1
Switched to context "cluster1".

> cluster1 안에 있는 node 2개 확인


student-node ~ ➜  kubectl get nodes
NAME                    STATUS   ROLES           AGE   VERSION
cluster1-controlplane   Ready    control-plane   39m   v1.24.0
cluster1-node01         Ready    <none>          39m   v1.24.0

> cluster2 안에 있는 node 2개 확인


student-node ~ ➜  kubectl config use-context cluster2
Switched to context "cluster2".

student-node ~ ➜
student-node ~ ➜  kubectl get nodes
NAME                    STATUS   ROLES           AGE   VERSION
cluster2-controlplane   Ready    control-plane   43m   v1.24.0
cluster2-node01         Ready    <none>          42m   v1.24.0

student-node ~ ➜

★ 여러개의 Cluster가 존재한다. 그 안에 node에 ssh로 접속하시오.


student-node ~ ➜  kubectl get nodes
NAME                    STATUS   ROLES           AGE   VERSION
cluster1-controlplane   Ready    control-plane   44m   v1.24.0
cluster1-node01         Ready    <none>          44m   v1.24.0

student-node ~ ➜  ssh cluster1-controlplane
Welcome to Ubuntu 18.04.6 LTS (GNU/Linux 5.4.0-1105-gcp x86_64)

* Documentation:  https://help.ubuntu.com
* Management:     https://landscape.canonical.com
* Support:        https://ubuntu.com/advantage
This system has been minimized by removing packages and content that are
not required on a system that users do not log into.

To restore this content, you can run the 'unminimize' command.

cluster1-controlplane ~ ➜

cluster1-controlplane ~ ➜  logout
Connection to cluster1-controlplane closed.

student-node ~ ➜

★ cluster1 안에 존재하는 ETCD를 확인하세요.

> 먼저 cluster1 클러스터로 바꾼다.


student-node ~ ➜  kubectl config use-context cluster1
Switched to context "cluster1".

student-node ~ ➜

> controlplane 노드를 확인한다.


student-node ~ ➜  kubectl get nodes
NAME                    STATUS   ROLES           AGE    VERSION
cluster1-controlplane   Ready    control-plane   100m   v1.24.0
cluster1-node01         Ready    <none>          99m    v1.24.0

student-node ~ ➜

> cluster1-controlplane에 들어간다.


student-node ~ ➜  ssh cluster1-controlplane
Welcome to Ubuntu 18.04.6 LTS (GNU/Linux 5.4.0-1105-gcp x86_64)

* Documentation:  https://help.ubuntu.com
* Management:     https://landscape.canonical.com
* Support:        https://ubuntu.com/advantage
This system has been minimized by removing packages and content that are
not required on a system that users do not log into.

To restore this content, you can run the 'unminimize' command.

cluster1-controlplane ~ ➜

> etcd 노드가 있는지 확인한다.


cluster1-controlplane ~ ➜  kubectl get pods -A
NAMESPACE     NAME                                            READY   STATUS    RESTARTS       AGE
kube-system   coredns-6d4b75cb6d-bfgs9                        1/1     Running   0              100m
kube-system   coredns-6d4b75cb6d-lftbq                        1/1     Running   0              100m
kube-system   etcd-cluster1-controlplane                      1/1     Running   0              101m
kube-system   kube-apiserver-cluster1-controlplane            1/1     Running   0              100m
kube-system   kube-controller-manager-cluster1-controlplane   1/1     Running   0              100m
kube-system   kube-proxy-45kft                                1/1     Running   0              100m
kube-system   kube-proxy-qmxkh                                1/1     Running   0              100m
kube-system   kube-scheduler-cluster1-controlplane            1/1     Running   0              100m
kube-system   weave-net-fwvfd                                 2/2     Running   0              100m
kube-system   weave-net-h9tg4                                 2/2     Running   1 (100m ago)   100m

cluster1-controlplane ~ ➜

★ cluster2 안에 존재하는 ETCD를 확인하세요.

> cluster2 클러스터로 바꾼다.


student-node ~ ➜  kubectl config use-context cluster2
Switched to context "cluster2".

student-node ~ ➜

> cluster2 클러스터안에 kube-system 네임스페이스안에 etcd가 들어가있는 pod가 있는지 확인한다.


student-node ~ ➜  kubectl get pods -n kube-system | grep etcd

student-node ~ ➜

> cluster2-controlplane 로 ssh 접속한다.


student-node ~ ➜  ssh cluster2-controlplane
Welcome to Ubuntu 18.04.6 LTS (GNU/Linux 5.4.0-1105-gcp x86_64)

* Documentation:  https://help.ubuntu.com
* Management:     https://landscape.canonical.com
* Support:        https://ubuntu.com/advantage
This system has been minimized by removing packages and content that are
not required on a system that users do not log into.

To restore this content, you can run the 'unminimize' command.
Last login: Sat May 27 11:31:10 2023 from 192.12.169.22

cluster2-controlplane ~ ➜

> manifests경로안에 etcd가 들어간 문자가 있는지 확인


cluster2-controlplane ~ ➜  ls /etc/kubernetes/manifests/ | grep -i etcd

cluster2-controlplane ~ ✖

> cluster2-controlplane 프로세스를 확인 kube-apiserver가 etcd 외부 데이터를 참조하고있는 것을 확인.


cluster2-controlplane ~ ➜  ps -ef | grep etcd
root        1754    1380  0 09:41 ?        00:06:24 kube-apiserver --advertise-address=192.12.169.3 --allow-privileged=true --authorization-mode=Node,RBAC --client-ca-file=/etc/kubernetes/pki/ca.crt --enable-admission-plugins=NodeRestriction --enable-bootstrap-token-auth=true --etcd-cafile=/etc/kubernetes/pki/etcd/ca.pem --etcd-certfile=/etc/kubernetes/pki/etcd/etcd.pem --etcd-keyfile=/etc/kubernetes/pki/etcd/etcd-key.pem --etcd-servers=https://192.12.169.15:2379 --kubelet-client-certificate=/etc/kubernetes/pki/apiserver-kubelet-client.crt --kubelet-client-key=/etc/kubernetes/pki/apiserver-kubelet-client.key --kubelet-preferred-address-types=InternalIP,ExternalIP,Hostname --proxy-client-cert-file=/etc/kubernetes/pki/front-proxy-client.crt --proxy-client-key-file=/etc/kubernetes/pki/front-proxy-client.key --requestheader-allowed-names=front-proxy-client --requestheader-client-ca-file=/etc/kubernetes/pki/front-proxy-ca.crt --requestheader-extra-headers-prefix=X-Remote-Extra- --requestheader-group-headers=X-Remote-Group --requestheader-username-headers=X-Remote-User --secure-port=6443 --service-account-issuer=https://kubernetes.default.svc.cluster.local --service-account-key-file=/etc/kubernetes/pki/sa.pub --service-account-signing-key-file=/etc/kubernetes/pki/sa.key --service-cluster-ip-range=10.96.0.0/12 --tls-cert-file=/etc/kubernetes/pki/apiserver.crt --tls-private-key-file=/etc/kubernetes/pki/apiserver.key
root       12885   11985  0 11:38 pts/0    00:00:00 grep etcd

cluster2-controlplane ~ ➜

> 또한 kube-apiserver 파드를 확인해보면 etcd경로가 나옵니다.


cluster2-controlplane ~ ➜  kubectl -n kube-system describe pods kube-apiserver-cluster2-controlplane
Name:                 kube-apiserver-cluster2-controlplane
Namespace:            kube-system
Priority:             2000001000
Priority Class Name:  system-node-critical
Node:                 cluster2-controlplane/192.12.169.3
Start Time:           Sat, 27 May 2023 09:42:04 +0000
Labels:               component=kube-apiserver
tier=control-plane
Annotations:          kubeadm.kubernetes.io/kube-apiserver.advertise-address.endpoint: 192.12.169.3:6443
kubernetes.io/config.hash: 227d76fd58a21baab84e0eee669ac726
kubernetes.io/config.mirror: 227d76fd58a21baab84e0eee669ac726
kubernetes.io/config.seen: 2023-05-27T09:42:02.804610708Z
kubernetes.io/config.source: file
seccomp.security.alpha.kubernetes.io/pod: runtime/default
Status:               Running
IP:                   192.12.169.3
IPs:
IP:           192.12.169.3
Controlled By:  Node/cluster2-controlplane
Containers:
kube-apiserver:
Container ID:  containerd://2f32b634619597cd782c9253de5a40154d160681168ced52481ffc333276a0dc
Image:         k8s.gcr.io/kube-apiserver:v1.24.0
Image ID:      k8s.gcr.io/kube-apiserver@sha256:a04522b882e919de6141b47d72393fb01226c78e7388400f966198222558c955
Port:          <none>
Host Port:     <none>
Command:
kube-apiserver
--advertise-address=192.12.169.3
--allow-privileged=true
--authorization-mode=Node,RBAC
--client-ca-file=/etc/kubernetes/pki/ca.crt
--enable-admission-plugins=NodeRestriction
--enable-bootstrap-token-auth=true
--etcd-cafile=/etc/kubernetes/pki/etcd/ca.pem
--etcd-certfile=/etc/kubernetes/pki/etcd/etcd.pem
--etcd-keyfile=/etc/kubernetes/pki/etcd/etcd-key.pem
--etcd-servers=https://192.12.169.15:2379

★ 내부에 연결된 ETCD 데이터가 어디에 쌓이는지 경로를 확인하세요.

> /var/lib/etcd


student-node ~ ➜  kubectl -n kube-system describe pods etcd-cluster1-controlplane
Name:                 etcd-cluster1-controlplane
Namespace:            kube-system
Priority:             2000001000
Priority Class Name:  system-node-critical
Node:                 cluster1-controlplane/192.12.169.24
Start Time:           Sat, 27 May 2023 09:42:42 +0000
Labels:               component=etcd
tier=control-plane
Annotations:          kubeadm.kubernetes.io/etcd.advertise-client-urls: https://192.12.169.24:2379
kubernetes.io/config.hash: e4db54d1749cdfee9674a1e9e140fd0b
kubernetes.io/config.mirror: e4db54d1749cdfee9674a1e9e140fd0b
kubernetes.io/config.seen: 2023-05-27T09:42:25.092806611Z
kubernetes.io/config.source: file
seccomp.security.alpha.kubernetes.io/pod: runtime/default
Status:               Running
IP:                   192.12.169.24
IPs:
IP:           192.12.169.24
Controlled By:  Node/cluster1-controlplane
Containers:
etcd:
...
Volumes:
etcd-certs:
Type:          HostPath (bare host directory volume)
Path:          /etc/kubernetes/pki/etcd
HostPathType:  DirectoryOrCreate
etcd-data:
Type:          HostPath (bare host directory volume)
Path:          /var/lib/etcd
HostPathType:  DirectoryOrCreate
QoS Class:         Burstable
Node-Selectors:    <none>
Tolerations:       :NoExecute op=Exists
Events:            <none>

★ 외부로 연결된 ETCD 데이터가 어디에 쌓이는지 경로를 확인하세요.

> cluster2-controlplane 노드로 ssh 접속 후 프로세스 확인

> etcd-server:https://192.12.169.15:2379 외부 IP 확인


cluster2-controlplane ~ ➜  ps -ef | grep etcd
root        1754    1380  0 09:41 ?        00:07:01 kube-apiserver --advertise-address=192.12.169.3 --allow-privileged=true --authorization-mode=Node,RBAC --client-ca-file=/etc/kubernetes/pki/ca.crt --enable-admission-plugins=NodeRestriction --enable-bootstrap-token-auth=true --etcd-cafile=/etc/kubernetes/pki/etcd/ca.pem --etcd-certfile=/etc/kubernetes/pki/etcd/etcd.pem --etcd-keyfile=/etc/kubernetes/pki/etcd/etcd-key.pem --etcd-servers=https://192.12.169.15:2379 --kubelet-client-certificate=/etc/kubernetes/pki/apiserver-kubelet-client.crt --kubelet-client-key=/etc/kubernetes/pki/apiserver-kubelet-client.key --kubelet-preferred-address-types=InternalIP,ExternalIP,Hostname --proxy-client-cert-file=/etc/kubernetes/pki/front-proxy-client.crt --proxy-client-key-file=/etc/kubernetes/pki/front-proxy-client.key --requestheader-allowed-names=front-proxy-client --requestheader-client-ca-file=/etc/kubernetes/pki/front-proxy-ca.crt --requestheader-extra-headers-prefix=X-Remote-Extra- --requestheader-group-headers=X-Remote-Group --requestheader-username-headers=X-Remote-User --secure-port=6443 --service-account-issuer=https://kubernetes.default.svc.cluster.local --service-account-key-file=/etc/kubernetes/pki/sa.pub --service-account-signing-key-file=/etc/kubernetes/pki/sa.key --service-cluster-ip-range=10.96.0.0/12 --tls-cert-file=/etc/kubernetes/pki/apiserver.crt --tls-private-key-file=/etc/kubernetes/pki/apiserver.key
root       14390   14207  0 11:50 pts/0    00:00:00 grep etcd

cluster2-controlplane ~ ➜

> 외부 etcd-server 접속


student-node ~ ➜ ssh 192.12.169.15
Welcome to Ubuntu 18.04.6 LTS (GNU/Linux 5.4.0-1105-gcp x86_64)

* Documentation:  https://help.ubuntu.com
* Management:     https://landscape.canonical.com
* Support:        https://ubuntu.com/advantage
This system has been minimized by removing packages and content that are
not required on a system that users do not log into.

To restore this content, you can run the 'unminimize' command.

etcd-server ~ ➜

> etcd-server에서 프로세스 확인

> data-dir=/var/lib/etcd-data


etcd-server ~ ➜ ps -ef | grep etcd
etcd         917       1  0 10:21 ?        00:01:25 /usr/local/bin/etcd --name etcd-server --data-dir=/var/lib/etcd-data --cert-file=/etc/etcd/pki/etcd.pem --key-file=/etc/etcd/pki/etcd-key.pem --peer-cert-file=/etc/etcd/pki/etcd.pem --peer-key-file=/etc/etcd/pki/etcd-key.pem --trusted-ca-file=/etc/etcd/pki/ca.pem --peer-trusted-ca-file=/etc/etcd/pki/ca.pem --peer-client-cert-auth --client-cert-auth --initial-advertise-peer-urls https://192.12.169.15:2380 --listen-peer-urls https://192.12.169.15:2380 --advertise-client-urls https://192.12.169.15:2379 --listen-client-urls https://192.12.169.15:2379,https://127.0.0.1:2379 --initial-cluster-token etcd-cluster-1 --initial-cluster etcd-server=https://192.12.169.15:2380 --initial-cluster-state new
root        1170    1005  0 11:51 pts/0    00:00:00 grep etcd

etcd-server ~ ➜

★ 외부에 연결된 etcd-server에 연결된 노드가 몇개인가요 ?

> 1개


etcd-server ~ ➜  ETCDCTL_API=3 etcdctl \
> --endpoints=https://127.0.0.1:2379 \
>  --cacert=/etc/etcd/pki/ca.pem \
>  --cert=/etc/etcd/pki/etcd.pem \
>  --key=/etc/etcd/pki/etcd-key.pem \
>   member list
c810de83f8ff6c49, started, etcd-server, https://192.12.169.15:2380, https://192.12.169.15:2379, false

etcd-server ~ ➜

★ cluster1의 etcd를 백업하자.

> cluster1로 바꾸기


student-node ~ ➜ kubectl config use-context cluster1
Switched to context "cluster1".

student-node ~ ➜

> etcd파드에서 사용하는 엔드포인트 정보를 확인한다. 해당 정보로 백업을 수행합니다.


student-node ~ ➜  kubectl describe  pods -n kube-system etcd-cluster1-controlplane  | grep advertise-client-urls
Annotations:          kubeadm.kubernetes.io/etcd.advertise-client-urls: https://192.12.169.24:2379
--advertise-client-urls=https://192.12.169.24:2379

student-node ~ ➜

> etcd파드에서 사용하는 인증서 정보를 확인한다. 해당 정보로 백업을 수행합니다.


student-node ~ ➜  kubectl describe pods -n kube-system etcd-cluster1-controlplane | grep pki
--cert-file=/etc/kubernetes/pki/etcd/server.crt
--key-file=/etc/kubernetes/pki/etcd/server.key
--peer-cert-file=/etc/kubernetes/pki/etcd/peer.crt
--peer-key-file=/etc/kubernetes/pki/etcd/peer.key
--peer-trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt
--trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt
/etc/kubernetes/pki/etcd from etcd-certs (rw)
Path:          /etc/kubernetes/pki/etcd

student-node ~ ➜

> 수집했던 정보로 스냅샷을 만들어 준다.


cluster1-controlplane ~ ➜  ETCDCTL_API=3 etcdctl --endpoints=https://192.12.169.24:2379 --cacert=/etc/kubernetes/pki/etcd/ca.crt --cert=/etc/kubernetes/pki/etcd/server.crt --key=/etc/kubernetes/pki/etcd/server.key snapshot save /opt/cluster1.db
Snapshot saved at /opt/cluster1.db

cluster1-controlplane ~ ➜
cluster1-controlplane ~ ➜  ls -al /opt/
total 2096
drwxr-xr-x 1 root root    4096 May 27 12:08 .
drwxr-xr-x 1 root root    4096 May 27 09:42 ..
-rw-r--r-- 1 root root 2117664 May 27 12:08 cluster1.db
drwxr-xr-x 1 root root    4096 Dec 20 10:08 cni
drwx--x--x 4 root root    4096 Dec 20 10:09 containerd

cluster1-controlplane ~ ➜

> 해당 노드를 나와서 밖에 노드로 복사해준다.


student-node ~ ✖ scp cluster1-controlplane:/opt/cluster1.db /opt
cluster1.db                                         100% 2068KB  83.8MB/s   00:00

student-node ~ ➜
student-node ~ ➜  ls -al /opt
total 2088
drwxr-xr-x 1 root root    4096 May 27 12:10 .
drwxr-xr-x 1 root root    4096 May 27 09:41 ..
-rw-r--r-- 1 root root 2117664 May 27 12:10 cluster1.db
drwxr-xr-x 1 root root    4096 May 27 09:41 .init

student-node ~ ➜

★ 가지고 있는 스냅샷으로 cluster2의 외부로 연결된 etcd를 복원해보자

> cluster2로 바꾸기


student-node ~ ➜  kubectl config use-context cluster2
Switched to context "cluster2".

student-node ~ ➜

> 가지고 있는 스냅샷 파일을 외부 etcd-server /root 경로에 복사


student-node ~ ➜  scp /opt/cluster2.db etcd-server:/root
cluster2.db                                         100% 2088KB 130.2MB/s   00:00

student-node ~ ➜

> 외부 etcd-serve로 ssh 접속


student-node ~ ➜  ssh 192.13.240.15
Welcome to Ubuntu 18.04.6 LTS (GNU/Linux 5.4.0-1105-gcp x86_64)

* Documentation:  https://help.ubuntu.com
* Management:     https://landscape.canonical.com
* Support:        https://ubuntu.com/advantage
This system has been minimized by removing packages and content that are
not required on a system that users do not log into.

To restore this content, you can run the 'unminimize' command.
Last login: Sat May 27 12:20:19 2023 from 192.13.240.21

etcd-server ~ ➜

> etcd-server에서 복원하는거니 127.0.0.1 사용, 인증서는 기본 사용, 데이터 경로는 /var/lib/etcd-data-new 사용


etcd-server ~ ➜  ETCDCTL_API=3 etcdctl --endpoints=https://127.0.0.1:2379 --cacert=/etc/etcd/pki/ca.pem --cert=/etc/etcd/pki/etcd.pem --key=/etc/etcd/pki/etcd-key.pem snapshot restore /root/cluster2.db --data-dir /var/lib/etcd-data-new
{"level":"info","ts":1685190548.319989,"caller":"snapshot/v3_snapshot.go:296","msg":"restoring snapshot","path":"/root/cluster2.db","wal-dir":"/var/lib/etcd-data-new/member/wal","data-dir":"/var/lib/etcd-data-new","snap-dir":"/var/lib/etcd-data-new/member/snap"}
{"level":"info","ts":1685190548.3370929,"caller":"mvcc/kvstore.go:388","msg":"restored last compact revision","meta-bucket-name":"meta","meta-bucket-name-key":"finishedCompactRev","restored-compact-revision":6336}
{"level":"info","ts":1685190548.3447402,"caller":"membership/cluster.go:392","msg":"added member","cluster-id":"cdf818194e3a8c32","local-member-id":"0","added-peer-id":"8e9e05c52164694d","added-peer-peer-urls":["http://localhost:2380"]}
{"level":"info","ts":1685190548.3543217,"caller":"snapshot/v3_snapshot.go:309","msg":"restored snapshot","path":"/root/cluster2.db","wal-dir":"/var/lib/etcd-data-new/member/wal","data-dir":"/var/lib/etcd-data-new","snap-dir":"/var/lib/etcd-data-new/member/snap"}

etcd-server ~ ➜

> etcd.service 파일에서 data-dir 부분을 /var/lib/etcd-data-new로 수정해주기


etcd-server ~ ➜  vi /etc/systemd/system/etcd.service
[Unit]
Description=etcd key-value store
Documentation=https://github.com/etcd-io/etcd
After=network.target

[Service]
User=etcd
Type=notify
ExecStart=/usr/local/bin/etcd \
--name etcd-server \
--data-dir=/var/lib/etcd-data \

> 새 디렉터리에 대한 권한이 올바른지 확인합니다 (etcd-server 가 권한을 가지고있어야 함):


etcd-server ~ ➜  chown -R etcd:etcd /var/lib/etcd-data-new/

etcd-server ~ ➜  ls -ld /var/lib/etcd-data-new/
drwx------ 3 etcd etcd 4096 May 27 12:29 /var/lib/etcd-data-new/

etcd-server ~ ➜

> etcd daemon 재시작 해주세요.


etcd-server ~ ➜  systemctl daemon-reload
etcd-server ~ ➜  systemctl restart etcd

> 마지막으로 전에 있는 정보에 의존하지 않도록 컨트롤플레인 구성 요소(예: kube-scheduler, kube-controller-manager, kubelet)를 재시작하는 것이 좋습니다.

저작자표시 (새창열림)

'Kubernetes > Kubernetes Exam' 카테고리의 다른 글

[K8s] CKA 취득 연습문제#6 (csr approve, reject) (0)	2023.05.30
[K8s] CKA 취득 연습문제#5 (etcd, apiserver 인증서) (0)	2023.05.29
[K8s] CKA 취득 연습문제#3 (etcd backup, snapshot) (0)	2023.05.20
[K8s] CKA 취득 연습문제#2 (node upgrade) (0)	2023.05.17
[K8s] CKA 취득 연습문제#1 (cordor, drain) (0)	2023.05.17

2023.05.20

★ 클러스터에서 실행 중인 ETCD의 버전은 무엇인가요?

-> etcd-version : 3.5.6


controlplane ~ ➜  kubectl -n kube-system logs etcd-controlplane | grep -i 'etcd-version'
{"level":"info","ts":"2023-05-20T05:14:33.291Z","caller":"embed/etcd.go:306","msg":"starting an etcd server","etcd-version":"3.5.6","git-sha":"cecbe35ce","go-version":"go1.16.15","go-os":"linux","go-arch":"amd64","max-cpu-set":36,"max-cpu-available":36,"member-initialized":false,"name":"controlplane","data-dir":"/var/lib/etcd","wal-dir":"","wal-dir-dedicated":"","member-dir":"/var/lib/etcd/member","force-new-cluster":false,"heartbeat-interval":"100ms","election-timeout":"1s","initial-election-tick-advance":true,"snapshot-count":10000,"max-wals":5,"max-snapshots":5,"snapshot-catchup-entries":5000,"initial-advertise-peer-urls":["https://192.6.237.3:2380"],"listen-peer-urls":["https://192.6.237.3:2380"],"advertise-client-urls":["https://192.6.237.3:2379"],"listen-client-urls":["https://127.0.0.1:2379","https://192.6.237.3:2379"],"listen-metrics-urls":["http://127.0.0.1:2381"],"cors":["*"],"host-whitelist":["*"],"initial-cluster":"controlplane=https://192.6.237.3:2380","initial-cluster-state":"new","initial-cluster-token":"etcd-cluster","quota-backend-bytes":2147483648,"max-request-bytes":1572864,"max-concurrent-streams":4294967295,"pre-vote":true,"initial-corrupt-check":true,"corrupt-check-time-interval":"0s","compact-check-time-enabled":false,"compact-check-time-interval":"1m0s","auto-compaction-mode":"periodic","auto-compaction-retention":"0s","auto-compaction-interval":"0s","discovery-url":"","discovery-proxy":"","downgrade-check-interval":"5s"}

controlplane ~ ➜

★ controlplane node에서 ETCD 클러스터에 연결할 수 있는 주소는 어디인가요?

-> https://127.0.0.1:2379


controlplane ~ ➜  kubectl -n kube-system describe pod etcd-controlplane | grep -i 'listen-client-url'
--listen-client-urls=https://127.0.0.1:2379,https://192.6.237.3:2379

controlplane ~ ➜

★ ETCD 서버 인증서 파일은 어디에 있나요?

-> --cert-file=/etc/kubernetes/pki/etcd/server.crt


controlplane ~ ➜  kubectl -n kube-system describe pod etcd-controlplane | grep -i 'cert-file'
--cert-file=/etc/kubernetes/pki/etcd/server.crt
--peer-cert-file=/etc/kubernetes/pki/etcd/peer.crt

controlplane ~ ➜

★ ETCD CA 인증서 파일은 어디에 있나요?

-> --peer-trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt


controlplane ~ ➜  kubectl -n kube-system describe pod etcd-controlplane | grep -i 'ca-file'
--peer-trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt
--trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt

controlplane ~ ➜

★ 클러스터의 master node는 오늘 밤에 재부팅이 예정되어 있습니다. 문제가 발생할 것으로 예상되지는 않지만 필요한 백업을 수행해야 합니다. 기본 제공 스냅샷 기능을 사용하여 ETCD 데이터베이스의 스냅샷을 만듭니다.

ETCDCTL_API=3 etcdctl --endpoints=https://[127.0.0.1]:2379 \
--cacert=/etc/kubernetes/pki/etcd/ca.crt \
--cert=/etc/kubernetes/pki/etcd/server.crt \
--key=/etc/kubernetes/pki/etcd/server.key \
snapshot save /opt/snapshot-pre-boot.db


controlplane ~ ➜ ETCDCTL_API=3 etcdctl --endpoints=https://[127.0.0.1]:2379 \
> --cacert=/etc/kubernetes/pki/etcd/ca.crt \
> --cert=/etc/kubernetes/pki/etcd/server.crt \
> --key=/etc/kubernetes/pki/etcd/server.key \
> snapshot save /opt/snapshot-pre-boot.db
Snapshot saved at /opt/snapshot-pre-boot.db

controlplane ~ ➜  ls /opt/
cni  containerd  snapshot-pre-boot.db

controlplane ~ ➜

★ 재부팅 후 마스터 노드가 다시 온라인 상태가 되었지만 애플리케이션에 액세스할 수 없습니다. 클러스터의 애플리케이션 상태를 확인하세요. 무슨 문제인가요?

- 배포가 없습니다.
- 서비스가 존재하지 않음
- 파드가 없음
위의 모든 것

★ 백업 파일을 사용하여 클러스터의 원래 상태를 복원합니다.


controlplane ~ ➜  ETCDCTL_API=3 etcdctl  --data-dir /var/lib/etcd-from-backup \
> snapshot restore /opt/snapshot-pre-boot.db
2023-05-20 02:06:58.280313 I | mvcc: restore compact to 2461
2023-05-20 02:06:58.287347 I | etcdserver/membership: added member 8e9e05c52164694d [http://localhost:2380] to cluster cdf818194e3a8c32

저작자표시 (새창열림)

'Kubernetes > Kubernetes Exam' 카테고리의 다른 글

[K8s] CKA 취득 연습문제#6 (csr approve, reject) (0)	2023.05.30
[K8s] CKA 취득 연습문제#5 (etcd, apiserver 인증서) (0)	2023.05.29
[K8s] CKA 취득 연습문제#4 (etcd backup, recovery) (0)	2023.05.24
[K8s] CKA 취득 연습문제#2 (node upgrade) (0)	2023.05.17
[K8s] CKA 취득 연습문제#1 (cordor, drain) (0)	2023.05.17

2023.05.20

★ Cluster 버전 확인

-> v1.25.0


controlplane ~ ➜  kubectl get nodes
NAME           STATUS   ROLES           AGE    VERSION
controlplane   Ready    control-plane   116m   v1.25.0
node01         Ready    <none>          116m   v1.25.0

controlplane ~ ➜

★ Worker node인 node는 어떤 노드인가요 ?

-> Taints 가 없으니 다 Worker node


controlplane ~ ➜  kubectl describe nodes controlplane | grep Taints
Taints:             <none>

controlplane ~ ➜  kubectl describe nodes node01 | grep Taints
Taints:             <none>

★ deploy되는 pods는 어떤 node에 올라가나요 ?

-> node01, controlplane


controlplane ~ ➜  kubectl get pods -o wide
NAME                    READY   STATUS    RESTARTS   AGE   IP           NODE           NOMINATED NODE   READINESS GATES
blue-5db6db69f7-94bd2   1/1     Running   0          14m   10.244.1.4   node01         <none>           <none>
blue-5db6db69f7-d4ckd   1/1     Running   0          14m   10.244.1.2   node01         <none>           <none>
blue-5db6db69f7-fgrvp   1/1     Running   0          14m   10.244.1.3   node01         <none>           <none>
blue-5db6db69f7-fkvdv   1/1     Running   0          14m   10.244.0.5   controlplane   <none>           <none>
blue-5db6db69f7-kcnkl   1/1     Running   0          14m   10.244.0.4   controlplane   <none>           <none>

★ 클러스터를 업그레이드하는 작업을 수행해야 합니다. 애플리케이션에 접속하는 사용자에게 영향을 미치지 않아야 하며 새 VM을 프로비저닝할 수 없습니다. 클러스터를 업그레이드하기 위해 어떤 방법을 사용하시겠습니까?

-> Worker node를 다른 노드로 이동하면서 한 번에 한 노드씩 업그레이드

★ 현재 쿠버네티스의 안정적인 최신 버전은 무엇인가요?

-> v1.27.2


controlplane ~ ➜  kubeadm upgrade plan
[upgrade/config] Making sure the configuration is correct:
[upgrade/config] Reading configuration from the cluster...
[upgrade/config] FYI: You can look at this config file with 'kubectl -n kube-system get cm kubeadm-config -o yaml'
[preflight] Running pre-flight checks.
[upgrade] Running cluster health checks
[upgrade] Fetching available versions to upgrade to
[upgrade/versions] Cluster version: v1.25.0
[upgrade/versions] kubeadm version: v1.25.0
I0519 23:10:12.713401   17274 version.go:256] remote version is much newer: v1.27.2; falling back to: stable-1.25
[upgrade/versions] Target version: v1.25.10
[upgrade/versions] Latest version in the v1.25 series: v1.25.10

★ 현재 버전의 kubeadm 도구가 설치된 상태에서 업그레이드할 수 있는 최신 버전은 무엇인가요?

-> v1.25.10


controlplane ~ ➜  kubeadm upgrade plan
[upgrade/config] Making sure the configuration is correct:
[upgrade/config] Reading configuration from the cluster...
[upgrade/config] FYI: You can look at this config file with 'kubectl -n kube-system get cm kubeadm-config -o yaml'
[preflight] Running pre-flight checks.
[upgrade] Running cluster health checks
[upgrade] Fetching available versions to upgrade to
[upgrade/versions] Cluster version: v1.25.0
[upgrade/versions] kubeadm version: v1.25.0
I0519 23:10:12.713401   17274 version.go:256] remote version is much newer: v1.27.2; falling back to: stable-1.25
[upgrade/versions] Target version: v1.25.10
[upgrade/versions] Latest version in the v1.25 series: v1.25.10

Components that must be upgraded manually after you have upgraded the control plane with 'kubeadm upgrade apply':
COMPONENT   CURRENT       TARGET
kubelet     2 x v1.25.0   v1.25.10

Upgrade to the latest version in the v1.25 series:

COMPONENT                 CURRENT   TARGET
kube-apiserver            v1.25.0   v1.25.10
kube-controller-manager   v1.25.0   v1.25.10
kube-scheduler            v1.25.0   v1.25.10
kube-proxy                v1.25.0   v1.25.10
CoreDNS                   v1.9.3    v1.9.3
etcd                      3.5.4-0   3.5.4-0

You can now apply the upgrade by executing the following command:

kubeadm upgrade apply v1.25.10

Note: Before you can perform this upgrade, you have to update kubeadm to v1.25.10.

★ controlplane node를 업그레이드할 것입니다. 컨트롤 플레인 노드에서 워크로드를 비우고 예약 불가능으로 설정해주세요.


controlplane ~ ✖ kubectl drain controlplane --ignore-daemonsets
node/controlplane already cordoned
Warning: ignoring DaemonSet-managed Pods: kube-flannel/kube-flannel-ds-qljgv, kube-system/kube-proxy-xkrtl
evicting pod kube-system/coredns-565d847f94-8ldgw
evicting pod default/blue-5db6db69f7-jhn5p
evicting pod default/blue-5db6db69f7-6pkjn
evicting pod kube-system/coredns-565d847f94-2bbdc
pod/blue-5db6db69f7-jhn5p evicted
pod/blue-5db6db69f7-6pkjn evicted
pod/coredns-565d847f94-2bbdc evicted
pod/coredns-565d847f94-8ldgw evicted
node/controlplane drained

controlplane ~ ➜

★ Controlplane node 업그레이드


controlplane ~ ➜  apt update
Get:1 https://packages.cloud.google.com/apt kubernetes-xenial InRelease [8,993 B]
Hit:2 https://download.docker.com/linux/ubuntu focal InRelease
...

controlplane ~ ➜  apt-get install kubeadm=1.26.0-00
Reading package lists... Done
Building dependency tree
Reading state information... Done
...

controlplane ~ ➜  kubeadm upgrade apply v1.26.0
[upgrade/config] Making sure the configuration is correct:
[upgrade/config] Reading configuration from the cluster...
...

controlplane ~ ➜  kubectl get nodes
NAME           STATUS                     ROLES           AGE   VERSION
controlplane   Ready,SchedulingDisabled   control-plane   85m   v1.26.0
node01         Ready                      <none>          84m   v1.25.0

controlplane ~ ➜

★ Controlplane node에서 예약 가능으로 설정하세요.


controlplane ~ ✖ kubectl uncordon controlplane
node/controlplane uncordoned

★ node01를 업그레이드할 것입니다. 워크로드를 비우고 예약 불가능으로 설정해주세요.

-> drain하게되면 node에 있던 pod들은 이동한다.


controlplane ~ ➜  kubectl drain node01 --ignore-daemonsets
node/node01 cordoned
Warning: ignoring DaemonSet-managed Pods: kube-flannel/kube-flannel-ds-2stnt, kube-system/kube-proxy-n5hmd
evicting pod kube-system/coredns-787d4945fb-lqjjv
evicting pod default/blue-5db6db69f7-225hb
evicting pod default/blue-5db6db69f7-c7ptb
evicting pod default/blue-5db6db69f7-gkbz4
evicting pod default/blue-5db6db69f7-r4rvt
evicting pod default/blue-5db6db69f7-tv2p9
evicting pod kube-system/coredns-787d4945fb-kr6xw
pod/blue-5db6db69f7-gkbz4 evicted
pod/blue-5db6db69f7-tv2p9 evicted
pod/blue-5db6db69f7-r4rvt evicted
pod/blue-5db6db69f7-225hb evicted
pod/blue-5db6db69f7-c7ptb evicted
pod/coredns-787d4945fb-kr6xw evicted
pod/coredns-787d4945fb-lqjjv evicted
node/node01 drained

controlplane ~ ➜  kubectl get pods -o wide
NAME                    READY   STATUS    RESTARTS   AGE   IP            NODE           NOMINATED NODE   READINESS GATES
blue-5db6db69f7-5sld2   1/1     Running   0          17s   10.244.0.7    controlplane   <none>           <none>
blue-5db6db69f7-9c4w2   1/1     Running   0          17s   10.244.0.12   controlplane   <none>           <none>
blue-5db6db69f7-9mhbr   1/1     Running   0          17s   10.244.0.9    controlplane   <none>           <none>
blue-5db6db69f7-j7tgx   1/1     Running   0          17s   10.244.0.11   controlplane   <none>           <none>
blue-5db6db69f7-p98g5   1/1     Running   0          17s   10.244.0.10   controlplane   <none>           <none>

controlplane ~ ➜

★ node01 업그레이드


controlplane ~ ➜  ssh node01

root@node01 ~ ➜  apt-get update
Get:2 http://archive.ubuntu.com/ubuntu focal InRelease [265 kB]
Get:3 https://download.docker.com/linux/ubuntu focal InRelease [57.7 kB]
Get:1 https://packages.cloud.google.com/apt kubernetes-xenial InRelease [8993 B]
...
root@node01 ~ ➜  apt-get install kubeadm=1.26.0-00
Reading package lists... Done
Building dependency tree
Reading state information... Done
...
oot@node01 ~ ➜  kubeadm upgrade node
[upgrade] Reading configuration from the cluster...
[upgrade] FYI: You can look at this config file with 'kubectl -n kube-system get cm kubeadm-config -o yaml'
[preflight] Running pre-flight checks
...
root@node01 ~ ➜  apt-get install kubelet=1.26.0-00
Reading package lists... Done
Building dependency tree
Reading state information... Done
...
root@node01 ~ ➜  systemctl daemon-reload
root@node01 ~ ➜  systemctl restart kubelet.service

controlplane ~ ➜  kubectl get node
NAME           STATUS                        ROLES           AGE    VERSION
controlplane   Ready                         control-plane   118m   v1.26.0
node01         NotReady,SchedulingDisabled   <none>          117m   v1.26.0

controlplane ~ ➜

★ node01 노드를 예약 가능으로 설정하세요.


controlplane ~ ➜  kubectl uncordon node01
node/node01 uncordoned

저작자표시 (새창열림)

'Kubernetes > Kubernetes Exam' 카테고리의 다른 글

[K8s] CKA 취득 연습문제#6 (csr approve, reject) (0)	2023.05.30
[K8s] CKA 취득 연습문제#5 (etcd, apiserver 인증서) (0)	2023.05.29
[K8s] CKA 취득 연습문제#4 (etcd backup, recovery) (0)	2023.05.24
[K8s] CKA 취득 연습문제#3 (etcd backup, snapshot) (0)	2023.05.20
[K8s] CKA 취득 연습문제#1 (cordor, drain) (0)	2023.05.17

2023.05.17

★ node 갯수 확인


controlplane ~ ➜  kubectl get nodes
NAME           STATUS   ROLES           AGE   VERSION
controlplane   Ready    control-plane   17m   v1.26.0
node01         Ready    <none>          17m   v1.26.0

controlplane ~ ➜

★ namespace가 default인 deploy를 찾아라


controlplane ~ ➜  kubectl get deployments.apps --namespace default
NAME   READY   UP-TO-DATE   AVAILABLE   AGE
blue   3/3     3            3           33s

controlplane ~ ➜

★ node관리를 위해 node01을 제거해야 한다. 애플리케이션의 노드를 비우고 예약 불가능으로 표시해주세요.


controlplane ~ ➜  kubectl drain node01 --ignore-daemonsets
node/node01 cordoned
Warning: ignoring DaemonSet-managed Pods: kube-flannel/kube-flannel-ds-bjcqz, kube-system/kube-proxy-l6ln5
evicting pod default/blue-987f68cb5-jt66v
evicting pod default/blue-987f68cb5-hw99q
pod/blue-987f68cb5-hw99q evicted
pod/blue-987f68cb5-jt66v evicted
node/node01 drained

controlplane ~ ➜

★ node관리 작업이 끝났다. 노드 node01을 다시 스케줄링할 수 있도록 구성


controlplane ~ ➜ kubectl uncordon node01
node/node01 uncordoned

controlplane ~ ➜

★ uncordon으로 노드 node01을 스케줄링 했지만 pods가 생성되지 않습니다. 원인은?

-> 노드에서 uncordon 명령을 실행해도 노드의 파드가 자동으로 스케줄링되지는 않습니다.

-> 새 파드가 생성되면 node01에 배치됩니다.

★ node01을 다시 drain 상태로 만들려고하는데 에러가 발생한다. 원인은?

-> node01에 pod가 예약된 것을 볼 수 있다.
-> 해당 경우 drain 명령은 작동하지 않는다. 노드를 강제로 drain하려면 이제 --force 옵션을 사용해야 한다


controlplane ~ ➜  kubectl get pods -o wide
NAME                   READY   STATUS    RESTARTS   AGE     IP           NODE           NOMINATED NODE   READINESS GATES
blue-987f68cb5-gbbq8   1/1     Running   0          11m     10.244.0.5   controlplane   <none>           <none>
blue-987f68cb5-gwvqs   1/1     Running   0          11m     10.244.0.4   controlplane   <none>           <none>
blue-987f68cb5-njps9   1/1     Running   0          11m     10.244.0.6   controlplane   <none>           <none>
hr-app                 1/1     Running   0          3m29s   10.244.1.4   node01         <none>           <none>

controlplane ~ ➜

★ node01 강제로 drain 했을 경우 hr-app pod는 어떻게 될까?

-> 사라져 버린다 ~


controlplane ~ ➜  kubectl drain node01 --ignore-daemonsets --force
node/node01 already cordoned
Warning: deleting Pods that declare no controller: default/hr-app; ignoring DaemonSet-managed Pods: kube-flannel/kube-flannel-ds-xhg7x, kube-system/kube-proxy-96vtg
evicting pod default/hr-app
pod/hr-app evicted
node/node01 drained

controlplane ~ ➜
controlplane ~ ➜  kubectl get pods -o wide
NAME                   READY   STATUS    RESTARTS   AGE   IP           NODE           NOMINATED NODE   READINESS GATES
blue-987f68cb5-gbbq8   1/1     Running   0          15m   10.244.0.5   controlplane   <none>           <none>
blue-987f68cb5-gwvqs   1/1     Running   0          15m   10.244.0.4   controlplane   <none>           <none>
blue-987f68cb5-njps9   1/1     Running   0          15m   10.244.0.6   controlplane   <none>           <none>

controlplane ~ ➜

★ hr-app pod는 굉장히 중요하므로 복구한다음 위험한 node01 노드에 배포되지 않게 설정해야합니다.


controlplane ~ ➜  kubectl get pods -o wide
NAME                      READY   STATUS    RESTARTS   AGE   IP           NODE           NOMINATED NODE   READINESS GATES
blue-987f68cb5-gbbq8      1/1     Running   0          16m   10.244.0.5   controlplane   <none>           <none>
blue-987f68cb5-gwvqs      1/1     Running   0          16m   10.244.0.4   controlplane   <none>           <none>
blue-987f68cb5-njps9      1/1     Running   0          16m   10.244.0.6   controlplane   <none>           <none>
hr-app-66c4c9c67f-78hm7   1/1     Running   0          47s   10.244.1.5   node01         <none>           <none>

controlplane ~ ➜
controlplane ~ ➜  kubectl cordon node01
node/node01 cordoned

controlplane ~ ➜

저작자표시 (새창열림)

'Kubernetes > Kubernetes Exam' 카테고리의 다른 글

[K8s] CKA 취득 연습문제#6 (csr approve, reject) (0)	2023.05.30
[K8s] CKA 취득 연습문제#5 (etcd, apiserver 인증서) (0)	2023.05.29
[K8s] CKA 취득 연습문제#4 (etcd backup, recovery) (0)	2023.05.24
[K8s] CKA 취득 연습문제#3 (etcd backup, snapshot) (0)	2023.05.20
[K8s] CKA 취득 연습문제#2 (node upgrade) (0)	2023.05.17

내 블로그 - 관리자 홈 전환	`Q` `Q`
새 글 쓰기	`W` `W`

글 수정 (권한 있는 경우)	`E` `E`
댓글 영역으로 이동	`C` `C`

이 페이지의 URL 복사	`S` `S`
맨 위로 이동	`T` `T`
티스토리 홈 이동	`H` `H`
단축키 안내	`Shift` + `/` `⇧` + `/`
