[K8s] CKA 취득 연습문제#4 (etcd backup, recovery)

2023. 5. 24. 22:55

2023.05.24

★ 여러개의 Cluster가 존재한다. 그 안에 node가 몇개인지 확인하시오.

> 클러스터 총 2개

student-node ~ ➜  kubectl config view
apiVersion: v1
clusters:
- cluster:
    certificate-authority-data: DATA+OMITTED
    server: https://cluster1-controlplane:6443
  name: cluster1
- cluster:
    certificate-authority-data: DATA+OMITTED
    server: https://192.12.169.3:6443
  name: cluster2
contexts:
- context:
    cluster: cluster1
    user: cluster1
  name: cluster1
- context:
    cluster: cluster2
    user: cluster2
  name: cluster2
current-context: cluster1
kind: Config
preferences: {}
users:
- name: cluster1
  user:
    client-certificate-data: REDACTED
    client-key-data: REDACTED
- name: cluster2
  user:
    client-certificate-data: REDACTED
    client-key-data: REDACTED

student-node ~ ➜

student-node ~ ➜ kubectl config use-context cluster
cluster1  cluster2

student-node ~ ➜ kubectl config use-context cluster1
Switched to context "cluster1".

> cluster1 안에 있는 node 2개 확인

student-node ~ ➜  kubectl get nodes
NAME                    STATUS   ROLES           AGE   VERSION
cluster1-controlplane   Ready    control-plane   39m   v1.24.0
cluster1-node01         Ready    <none>          39m   v1.24.0

> cluster2 안에 있는 node 2개 확인

student-node ~ ➜  kubectl config use-context cluster2
Switched to context "cluster2".

student-node ~ ➜
student-node ~ ➜  kubectl get nodes
NAME                    STATUS   ROLES           AGE   VERSION
cluster2-controlplane   Ready    control-plane   43m   v1.24.0
cluster2-node01         Ready    <none>          42m   v1.24.0

student-node ~ ➜

★ 여러개의 Cluster가 존재한다. 그 안에 node에 ssh로 접속하시오.

student-node ~ ➜  kubectl get nodes
NAME                    STATUS   ROLES           AGE   VERSION
cluster1-controlplane   Ready    control-plane   44m   v1.24.0
cluster1-node01         Ready    <none>          44m   v1.24.0

student-node ~ ➜  ssh cluster1-controlplane
Welcome to Ubuntu 18.04.6 LTS (GNU/Linux 5.4.0-1105-gcp x86_64)

 * Documentation:  https://help.ubuntu.com
 * Management:     https://landscape.canonical.com
 * Support:        https://ubuntu.com/advantage
This system has been minimized by removing packages and content that are
not required on a system that users do not log into.

To restore this content, you can run the 'unminimize' command.

cluster1-controlplane ~ ➜

cluster1-controlplane ~ ➜  logout
Connection to cluster1-controlplane closed.

student-node ~ ➜

★ cluster1 안에 존재하는 ETCD를 확인하세요.

> 먼저 cluster1 클러스터로 바꾼다.

student-node ~ ➜  kubectl config use-context cluster1
Switched to context "cluster1".

student-node ~ ➜

> controlplane 노드를 확인한다.

student-node ~ ➜  kubectl get nodes
NAME                    STATUS   ROLES           AGE    VERSION
cluster1-controlplane   Ready    control-plane   100m   v1.24.0
cluster1-node01         Ready    <none>          99m    v1.24.0

student-node ~ ➜

> cluster1-controlplane에 들어간다.

student-node ~ ➜  ssh cluster1-controlplane
Welcome to Ubuntu 18.04.6 LTS (GNU/Linux 5.4.0-1105-gcp x86_64)

 * Documentation:  https://help.ubuntu.com
 * Management:     https://landscape.canonical.com
 * Support:        https://ubuntu.com/advantage
This system has been minimized by removing packages and content that are
not required on a system that users do not log into.

To restore this content, you can run the 'unminimize' command.

cluster1-controlplane ~ ➜

> etcd 노드가 있는지 확인한다.

cluster1-controlplane ~ ➜  kubectl get pods -A
NAMESPACE     NAME                                            READY   STATUS    RESTARTS       AGE
kube-system   coredns-6d4b75cb6d-bfgs9                        1/1     Running   0              100m
kube-system   coredns-6d4b75cb6d-lftbq                        1/1     Running   0              100m
kube-system   etcd-cluster1-controlplane                      1/1     Running   0              101m
kube-system   kube-apiserver-cluster1-controlplane            1/1     Running   0              100m
kube-system   kube-controller-manager-cluster1-controlplane   1/1     Running   0              100m
kube-system   kube-proxy-45kft                                1/1     Running   0              100m
kube-system   kube-proxy-qmxkh                                1/1     Running   0              100m
kube-system   kube-scheduler-cluster1-controlplane            1/1     Running   0              100m
kube-system   weave-net-fwvfd                                 2/2     Running   0              100m
kube-system   weave-net-h9tg4                                 2/2     Running   1 (100m ago)   100m

cluster1-controlplane ~ ➜

★ cluster2 안에 존재하는 ETCD를 확인하세요.

> cluster2 클러스터로 바꾼다.

student-node ~ ➜  kubectl config use-context cluster2
Switched to context "cluster2".

student-node ~ ➜

> cluster2 클러스터안에 kube-system 네임스페이스안에 etcd가 들어가있는 pod가 있는지 확인한다.

student-node ~ ➜  kubectl get pods -n kube-system | grep etcd

student-node ~ ➜

> cluster2-controlplane 로 ssh 접속한다.

student-node ~ ➜  ssh cluster2-controlplane
Welcome to Ubuntu 18.04.6 LTS (GNU/Linux 5.4.0-1105-gcp x86_64)

 * Documentation:  https://help.ubuntu.com
 * Management:     https://landscape.canonical.com
 * Support:        https://ubuntu.com/advantage
This system has been minimized by removing packages and content that are
not required on a system that users do not log into.

To restore this content, you can run the 'unminimize' command.
Last login: Sat May 27 11:31:10 2023 from 192.12.169.22

cluster2-controlplane ~ ➜

> manifests경로안에 etcd가 들어간 문자가 있는지 확인

cluster2-controlplane ~ ➜  ls /etc/kubernetes/manifests/ | grep -i etcd

cluster2-controlplane ~ ✖

> cluster2-controlplane 프로세스를 확인 kube-apiserver가 etcd 외부 데이터를 참조하고있는 것을 확인.

cluster2-controlplane ~ ➜  ps -ef | grep etcd
root        1754    1380  0 09:41 ?        00:06:24 kube-apiserver --advertise-address=192.12.169.3 --allow-privileged=true --authorization-mode=Node,RBAC --client-ca-file=/etc/kubernetes/pki/ca.crt --enable-admission-plugins=NodeRestriction --enable-bootstrap-token-auth=true --etcd-cafile=/etc/kubernetes/pki/etcd/ca.pem --etcd-certfile=/etc/kubernetes/pki/etcd/etcd.pem --etcd-keyfile=/etc/kubernetes/pki/etcd/etcd-key.pem --etcd-servers=https://192.12.169.15:2379 --kubelet-client-certificate=/etc/kubernetes/pki/apiserver-kubelet-client.crt --kubelet-client-key=/etc/kubernetes/pki/apiserver-kubelet-client.key --kubelet-preferred-address-types=InternalIP,ExternalIP,Hostname --proxy-client-cert-file=/etc/kubernetes/pki/front-proxy-client.crt --proxy-client-key-file=/etc/kubernetes/pki/front-proxy-client.key --requestheader-allowed-names=front-proxy-client --requestheader-client-ca-file=/etc/kubernetes/pki/front-proxy-ca.crt --requestheader-extra-headers-prefix=X-Remote-Extra- --requestheader-group-headers=X-Remote-Group --requestheader-username-headers=X-Remote-User --secure-port=6443 --service-account-issuer=https://kubernetes.default.svc.cluster.local --service-account-key-file=/etc/kubernetes/pki/sa.pub --service-account-signing-key-file=/etc/kubernetes/pki/sa.key --service-cluster-ip-range=10.96.0.0/12 --tls-cert-file=/etc/kubernetes/pki/apiserver.crt --tls-private-key-file=/etc/kubernetes/pki/apiserver.key
root       12885   11985  0 11:38 pts/0    00:00:00 grep etcd

cluster2-controlplane ~ ➜

> 또한 kube-apiserver 파드를 확인해보면 etcd경로가 나옵니다.

cluster2-controlplane ~ ➜  kubectl -n kube-system describe pods kube-apiserver-cluster2-controlplane
Name:                 kube-apiserver-cluster2-controlplane
Namespace:            kube-system
Priority:             2000001000
Priority Class Name:  system-node-critical
Node:                 cluster2-controlplane/192.12.169.3
Start Time:           Sat, 27 May 2023 09:42:04 +0000
Labels:               component=kube-apiserver
                      tier=control-plane
Annotations:          kubeadm.kubernetes.io/kube-apiserver.advertise-address.endpoint: 192.12.169.3:6443
                      kubernetes.io/config.hash: 227d76fd58a21baab84e0eee669ac726
                      kubernetes.io/config.mirror: 227d76fd58a21baab84e0eee669ac726
                      kubernetes.io/config.seen: 2023-05-27T09:42:02.804610708Z
                      kubernetes.io/config.source: file
                      seccomp.security.alpha.kubernetes.io/pod: runtime/default
Status:               Running
IP:                   192.12.169.3
IPs:
  IP:           192.12.169.3
Controlled By:  Node/cluster2-controlplane
Containers:
  kube-apiserver:
    Container ID:  containerd://2f32b634619597cd782c9253de5a40154d160681168ced52481ffc333276a0dc
    Image:         k8s.gcr.io/kube-apiserver:v1.24.0
    Image ID:      k8s.gcr.io/kube-apiserver@sha256:a04522b882e919de6141b47d72393fb01226c78e7388400f966198222558c955
    Port:          <none>
    Host Port:     <none>
    Command:
      kube-apiserver
      --advertise-address=192.12.169.3
      --allow-privileged=true
      --authorization-mode=Node,RBAC
      --client-ca-file=/etc/kubernetes/pki/ca.crt
      --enable-admission-plugins=NodeRestriction
      --enable-bootstrap-token-auth=true
      --etcd-cafile=/etc/kubernetes/pki/etcd/ca.pem
      --etcd-certfile=/etc/kubernetes/pki/etcd/etcd.pem
      --etcd-keyfile=/etc/kubernetes/pki/etcd/etcd-key.pem
      --etcd-servers=https://192.12.169.15:2379

★ 내부에 연결된 ETCD 데이터가 어디에 쌓이는지 경로를 확인하세요.

> /var/lib/etcd

student-node ~ ➜  kubectl -n kube-system describe pods etcd-cluster1-controlplane
Name:                 etcd-cluster1-controlplane
Namespace:            kube-system
Priority:             2000001000
Priority Class Name:  system-node-critical
Node:                 cluster1-controlplane/192.12.169.24
Start Time:           Sat, 27 May 2023 09:42:42 +0000
Labels:               component=etcd
                      tier=control-plane
Annotations:          kubeadm.kubernetes.io/etcd.advertise-client-urls: https://192.12.169.24:2379
                      kubernetes.io/config.hash: e4db54d1749cdfee9674a1e9e140fd0b
                      kubernetes.io/config.mirror: e4db54d1749cdfee9674a1e9e140fd0b
                      kubernetes.io/config.seen: 2023-05-27T09:42:25.092806611Z
                      kubernetes.io/config.source: file
                      seccomp.security.alpha.kubernetes.io/pod: runtime/default
Status:               Running
IP:                   192.12.169.24
IPs:
  IP:           192.12.169.24
Controlled By:  Node/cluster1-controlplane
Containers:
  etcd:
...
Volumes:
  etcd-certs:
    Type:          HostPath (bare host directory volume)
    Path:          /etc/kubernetes/pki/etcd
    HostPathType:  DirectoryOrCreate
  etcd-data:
    Type:          HostPath (bare host directory volume)
    Path:          /var/lib/etcd
    HostPathType:  DirectoryOrCreate
QoS Class:         Burstable
Node-Selectors:    <none>
Tolerations:       :NoExecute op=Exists
Events:            <none>

★ 외부로 연결된 ETCD 데이터가 어디에 쌓이는지 경로를 확인하세요.

> cluster2-controlplane 노드로 ssh 접속 후 프로세스 확인

> etcd-server:https://192.12.169.15:2379 외부 IP 확인

cluster2-controlplane ~ ➜  ps -ef | grep etcd
root        1754    1380  0 09:41 ?        00:07:01 kube-apiserver --advertise-address=192.12.169.3 --allow-privileged=true --authorization-mode=Node,RBAC --client-ca-file=/etc/kubernetes/pki/ca.crt --enable-admission-plugins=NodeRestriction --enable-bootstrap-token-auth=true --etcd-cafile=/etc/kubernetes/pki/etcd/ca.pem --etcd-certfile=/etc/kubernetes/pki/etcd/etcd.pem --etcd-keyfile=/etc/kubernetes/pki/etcd/etcd-key.pem --etcd-servers=https://192.12.169.15:2379 --kubelet-client-certificate=/etc/kubernetes/pki/apiserver-kubelet-client.crt --kubelet-client-key=/etc/kubernetes/pki/apiserver-kubelet-client.key --kubelet-preferred-address-types=InternalIP,ExternalIP,Hostname --proxy-client-cert-file=/etc/kubernetes/pki/front-proxy-client.crt --proxy-client-key-file=/etc/kubernetes/pki/front-proxy-client.key --requestheader-allowed-names=front-proxy-client --requestheader-client-ca-file=/etc/kubernetes/pki/front-proxy-ca.crt --requestheader-extra-headers-prefix=X-Remote-Extra- --requestheader-group-headers=X-Remote-Group --requestheader-username-headers=X-Remote-User --secure-port=6443 --service-account-issuer=https://kubernetes.default.svc.cluster.local --service-account-key-file=/etc/kubernetes/pki/sa.pub --service-account-signing-key-file=/etc/kubernetes/pki/sa.key --service-cluster-ip-range=10.96.0.0/12 --tls-cert-file=/etc/kubernetes/pki/apiserver.crt --tls-private-key-file=/etc/kubernetes/pki/apiserver.key
root       14390   14207  0 11:50 pts/0    00:00:00 grep etcd

cluster2-controlplane ~ ➜

> 외부 etcd-server 접속

student-node ~ ➜ ssh 192.12.169.15
Welcome to Ubuntu 18.04.6 LTS (GNU/Linux 5.4.0-1105-gcp x86_64)

 * Documentation:  https://help.ubuntu.com
 * Management:     https://landscape.canonical.com
 * Support:        https://ubuntu.com/advantage
This system has been minimized by removing packages and content that are
not required on a system that users do not log into.

To restore this content, you can run the 'unminimize' command.

etcd-server ~ ➜

> etcd-server에서 프로세스 확인

> data-dir=/var/lib/etcd-data

etcd-server ~ ➜ ps -ef | grep etcd
etcd         917       1  0 10:21 ?        00:01:25 /usr/local/bin/etcd --name etcd-server --data-dir=/var/lib/etcd-data --cert-file=/etc/etcd/pki/etcd.pem --key-file=/etc/etcd/pki/etcd-key.pem --peer-cert-file=/etc/etcd/pki/etcd.pem --peer-key-file=/etc/etcd/pki/etcd-key.pem --trusted-ca-file=/etc/etcd/pki/ca.pem --peer-trusted-ca-file=/etc/etcd/pki/ca.pem --peer-client-cert-auth --client-cert-auth --initial-advertise-peer-urls https://192.12.169.15:2380 --listen-peer-urls https://192.12.169.15:2380 --advertise-client-urls https://192.12.169.15:2379 --listen-client-urls https://192.12.169.15:2379,https://127.0.0.1:2379 --initial-cluster-token etcd-cluster-1 --initial-cluster etcd-server=https://192.12.169.15:2380 --initial-cluster-state new
root        1170    1005  0 11:51 pts/0    00:00:00 grep etcd

etcd-server ~ ➜

★ 외부에 연결된 etcd-server에 연결된 노드가 몇개인가요 ?

> 1개

etcd-server ~ ➜  ETCDCTL_API=3 etcdctl \
> --endpoints=https://127.0.0.1:2379 \
>  --cacert=/etc/etcd/pki/ca.pem \
>  --cert=/etc/etcd/pki/etcd.pem \
>  --key=/etc/etcd/pki/etcd-key.pem \
>   member list
c810de83f8ff6c49, started, etcd-server, https://192.12.169.15:2380, https://192.12.169.15:2379, false

etcd-server ~ ➜

★ cluster1의 etcd를 백업하자.

> cluster1로 바꾸기

student-node ~ ➜ kubectl config use-context cluster1
Switched to context "cluster1".

student-node ~ ➜

> etcd파드에서 사용하는 엔드포인트 정보를 확인한다. 해당 정보로 백업을 수행합니다.

student-node ~ ➜  kubectl describe  pods -n kube-system etcd-cluster1-controlplane  | grep advertise-client-urls
Annotations:          kubeadm.kubernetes.io/etcd.advertise-client-urls: https://192.12.169.24:2379
      --advertise-client-urls=https://192.12.169.24:2379

student-node ~ ➜

> etcd파드에서 사용하는 인증서 정보를 확인한다. 해당 정보로 백업을 수행합니다.

student-node ~ ➜  kubectl describe pods -n kube-system etcd-cluster1-controlplane | grep pki
      --cert-file=/etc/kubernetes/pki/etcd/server.crt
      --key-file=/etc/kubernetes/pki/etcd/server.key
      --peer-cert-file=/etc/kubernetes/pki/etcd/peer.crt
      --peer-key-file=/etc/kubernetes/pki/etcd/peer.key
      --peer-trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt
      --trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt
      /etc/kubernetes/pki/etcd from etcd-certs (rw)
    Path:          /etc/kubernetes/pki/etcd

student-node ~ ➜

> 수집했던 정보로 스냅샷을 만들어 준다.

cluster1-controlplane ~ ➜  ETCDCTL_API=3 etcdctl --endpoints=https://192.12.169.24:2379 --cacert=/etc/kubernetes/pki/etcd/ca.crt --cert=/etc/kubernetes/pki/etcd/server.crt --key=/etc/kubernetes/pki/etcd/server.key snapshot save /opt/cluster1.db
Snapshot saved at /opt/cluster1.db

cluster1-controlplane ~ ➜
cluster1-controlplane ~ ➜  ls -al /opt/
total 2096
drwxr-xr-x 1 root root    4096 May 27 12:08 .
drwxr-xr-x 1 root root    4096 May 27 09:42 ..
-rw-r--r-- 1 root root 2117664 May 27 12:08 cluster1.db
drwxr-xr-x 1 root root    4096 Dec 20 10:08 cni
drwx--x--x 4 root root    4096 Dec 20 10:09 containerd

cluster1-controlplane ~ ➜

> 해당 노드를 나와서 밖에 노드로 복사해준다.

student-node ~ ✖ scp cluster1-controlplane:/opt/cluster1.db /opt
cluster1.db                                         100% 2068KB  83.8MB/s   00:00

student-node ~ ➜
student-node ~ ➜  ls -al /opt
total 2088
drwxr-xr-x 1 root root    4096 May 27 12:10 .
drwxr-xr-x 1 root root    4096 May 27 09:41 ..
-rw-r--r-- 1 root root 2117664 May 27 12:10 cluster1.db
drwxr-xr-x 1 root root    4096 May 27 09:41 .init

student-node ~ ➜

★ 가지고 있는 스냅샷으로 cluster2의 외부로 연결된 etcd를 복원해보자

> cluster2로 바꾸기

student-node ~ ➜  kubectl config use-context cluster2
Switched to context "cluster2".

student-node ~ ➜

> 가지고 있는 스냅샷 파일을 외부 etcd-server /root 경로에 복사

student-node ~ ➜  scp /opt/cluster2.db etcd-server:/root
cluster2.db                                         100% 2088KB 130.2MB/s   00:00

student-node ~ ➜

> 외부 etcd-serve로 ssh 접속

student-node ~ ➜  ssh 192.13.240.15
Welcome to Ubuntu 18.04.6 LTS (GNU/Linux 5.4.0-1105-gcp x86_64)

 * Documentation:  https://help.ubuntu.com
 * Management:     https://landscape.canonical.com
 * Support:        https://ubuntu.com/advantage
This system has been minimized by removing packages and content that are
not required on a system that users do not log into.

To restore this content, you can run the 'unminimize' command.
Last login: Sat May 27 12:20:19 2023 from 192.13.240.21

etcd-server ~ ➜

> etcd-server에서 복원하는거니 127.0.0.1 사용, 인증서는 기본 사용, 데이터 경로는 /var/lib/etcd-data-new 사용

etcd-server ~ ➜  ETCDCTL_API=3 etcdctl --endpoints=https://127.0.0.1:2379 --cacert=/etc/etcd/pki/ca.pem --cert=/etc/etcd/pki/etcd.pem --key=/etc/etcd/pki/etcd-key.pem snapshot restore /root/cluster2.db --data-dir /var/lib/etcd-data-new
{"level":"info","ts":1685190548.319989,"caller":"snapshot/v3_snapshot.go:296","msg":"restoring snapshot","path":"/root/cluster2.db","wal-dir":"/var/lib/etcd-data-new/member/wal","data-dir":"/var/lib/etcd-data-new","snap-dir":"/var/lib/etcd-data-new/member/snap"}
{"level":"info","ts":1685190548.3370929,"caller":"mvcc/kvstore.go:388","msg":"restored last compact revision","meta-bucket-name":"meta","meta-bucket-name-key":"finishedCompactRev","restored-compact-revision":6336}
{"level":"info","ts":1685190548.3447402,"caller":"membership/cluster.go:392","msg":"added member","cluster-id":"cdf818194e3a8c32","local-member-id":"0","added-peer-id":"8e9e05c52164694d","added-peer-peer-urls":["http://localhost:2380"]}
{"level":"info","ts":1685190548.3543217,"caller":"snapshot/v3_snapshot.go:309","msg":"restored snapshot","path":"/root/cluster2.db","wal-dir":"/var/lib/etcd-data-new/member/wal","data-dir":"/var/lib/etcd-data-new","snap-dir":"/var/lib/etcd-data-new/member/snap"}

etcd-server ~ ➜

> etcd.service 파일에서 data-dir 부분을 /var/lib/etcd-data-new로 수정해주기

etcd-server ~ ➜  vi /etc/systemd/system/etcd.service
[Unit]
Description=etcd key-value store
Documentation=https://github.com/etcd-io/etcd
After=network.target

[Service]
User=etcd
Type=notify
ExecStart=/usr/local/bin/etcd \
  --name etcd-server \
  --data-dir=/var/lib/etcd-data \

> 새 디렉터리에 대한 권한이 올바른지 확인합니다 (etcd-server 가 권한을 가지고있어야 함):

etcd-server ~ ➜  chown -R etcd:etcd /var/lib/etcd-data-new/

etcd-server ~ ➜  ls -ld /var/lib/etcd-data-new/
drwx------ 3 etcd etcd 4096 May 27 12:29 /var/lib/etcd-data-new/

etcd-server ~ ➜

> etcd daemon 재시작 해주세요.

etcd-server ~ ➜  systemctl daemon-reload
etcd-server ~ ➜  systemctl restart etcd

> 마지막으로 전에 있는 정보에 의존하지 않도록 컨트롤플레인 구성 요소(예: kube-scheduler, kube-controller-manager, kubelet)를 재시작하는 것이 좋습니다.

저작자표시

'Kubernetes > Kubernetes Exam' 카테고리의 다른 글

[K8s] CKA 취득 연습문제#6 (csr approve, reject) (0)	2023.05.30
[K8s] CKA 취득 연습문제#5 (etcd, apiserver 인증서) (0)	2023.05.29
[K8s] CKA 취득 연습문제#3 (etcd backup, snapshot) (0)	2023.05.20
[K8s] CKA 취득 연습문제#2 (node upgrade) (0)	2023.05.17
[K8s] CKA 취득 연습문제#1 (cordor, drain) (0)	2023.05.17

IT 끄적이는 물고기
